relative pressure transmitter / piezoresistive / membrane / analog output
LEO3

Add to MyDirectIndustry favorites
Compare this product Don’t compare this product
relative pressure transmitter / piezoresistive / membrane / analog output relative pressure transmitter / piezoresistive / membrane / analog output - LEO3
{{requestButtons}}

Characteristics

  • Pressure type:

    relative

  • Technology:

    piezoresistive, membrane

  • Output signal:

    analog output, digital output

  • Mounting:

    panel-mount

  • Other characteristics:

    stainless steel, IP65

  • Process temperature:

    Max.: 60 °C (140 °F)

    Min.: -10 °C (14 °F)

  • Pressure range:

    Max.: 1,000 bar (14,503.77 psi)

    Min.: 0 bar (0 psi)

Description

The LEO3 pressure transmitter is based on a microprocessor and equipped with dual display for pressure (upper section) and output signal (lower section), that is powered by the current loop of 4-20 mA. The control interface is located on the front panel and allows functions such as MAX/MIN (displaying values in the upper display part for 5 seconds, then reverting back to analog signal), RESET (sets min/max values to current value), ZERO SET (values set to zero pressure), ZERO R&D (values set do factory default) and units (allows selection of display units: bar, mbar / hPa, kPa, MPa, PSI, kp / cm²). The analogue output can also be programmed using the front panel buttons, allowing functions such as OUTP SETT, ZERO, FS and FACT SETT.
