Aluminum coupling RBC … EWC-ALU

with clampfor encodersfor spindles

The Single Beam Coupling RBC … EWC-ALU is a small, clamp-style aluminium single-beam coupling designed for backlash-free, angle-synchronous transmission of rotary movements in light-duty applications while optimally compensating shaft misalignments.

Features

• Small coupling for universal use
• Backlash-free, angle-synchronous transmission of rotary movements
• Designed for light applications
• Made of aluminium 7075-T6 (material no. 3.4365)
• Optimum compensation of shaft misalignments

Typical application

• Encoders
• Tachogenerators
• Spindle drives

Available variants (webshop table rows)

• RBC 0015 EWC-ALU-003.000-003.000 — Article number: 4417-115100-003.00 — Weight: 9,0 — d1: 3 mm — d2: 3 mm — Delivery time: 10 Days — Price/piece: 49,41 €
• RBC 0015 EWC-ALU-004.000-003.000 — Article number: 4417-115100-M20528 — Weight: 9,0 — d1: 4 mm — d2: 3 mm — Delivery time: 10 Days — Price/piece: 49,41 €
• RBC 0015 EWC-ALU-004.000-004.000 — Article number: 4417-115100-004.00 — Weight: 9,0 — d1: 4 mm — d2: 4 mm — Delivery time: 10 Days — Price/piece: 49,41 €
• RBC 0015 EWC-ALU-005.000-003.000 — Article number: 4417-115100-M20532 — Weight: 9,0 — d1: 5 mm — d2: 3 mm — Delivery time: 10 Days — Price/piece: 49,41 €
• RBC 0015 EWC-ALU-005.000-004.000 — Article number: 4417-115100-M20535 — Weight: 9,0 — d1: 5 mm — d2: 4 mm — Delivery time: 10 Days — Price/piece: 49,41 €
• RBC 0015 EWC-ALU-005.000-005.000 — Article number: 4417-115100-005.00 — Weight: 9,0 — d1: 5 mm — d2: 5 mm — Delivery time: 10 Days — Price/piece: 49,41 €
• RBC 0020 EWC-ALU-004.000-004.000 — Article number: 4417-120100-004.00 — Weight: 21,0 — d1: 4 mm — d2: 4 mm — Delivery time: 10 Days — Price/piece: 50,40 €
• RBC 0020 EWC-ALU-005.000-004.000 — Article number: 4417-120100-M20535 — Weight: 21,0 — d1: 5 mm — d2: 4 mm — Delivery time: 10 Days — Price/piece: 50,40 €
• RBC 0020 EWC-ALU-005.000-005.000 — Article number: 4417-120100-005.00 — Weight: 21,0 — d1: 5 mm — d2: 5 mm — Delivery time: 10 Days — Price/piece: 50,40 €
• RBC 0020 EWC-ALU-006.000-004.000 — Article number: 4417-120100-M20542 — Weight: 21,0 — d1: 6 mm — d2: 4 mm — Delivery time: 10 Days — Price/piece: 50,40 €
• RBC 0020 EWC-ALU-006.000-005.000 — Article number: 4417-120100-M20543 — Weight: 21,0 — d1: 6 mm — d2: 5 mm — Delivery time: 10 Days — Price/piece: 50,40 €
• RBC 0020 EWC-ALU-006.000-006.000 — Article number: 4417-120100-006.00 — Weight: 21,0 — d1: 6 mm — d2: 6 mm — Delivery time: On request — Price/piece: 50,40 €
• RBC 0025 EWC-ALU-006.000-006.000 — Article number: 4417-125100-006.00 — Weight: 35,0 — d1: 6 mm — d2: 6 mm — Delivery time: 10 Days — Price/piece: 58,20 €
• RBC 0025 EWC-ALU-008.000-006.000 — Article number: 4417-125100-M20559 — Weight: 35,0 — d1: 8 mm — d2: 6 mm — Delivery time: 10 Days — Price/piece: 58,20 €
• RBC 0025 EWC-ALU-008.000-008.000 — Article number: 4417-125100-008.00 — Weight: 35,0 — d1: 8 mm — d2: 8 mm — Delivery time: 10 Days — Price/piece: 58,20 €
• RBC 0025 EWC-ALU-010.000-006.000 — Article number: 4417-125100-M20579 — Weight: 35,0 — d1: 10 mm — d2: 6 mm — Delivery time: 10 Days — Price/piece: 58,20 €
• RBC 0025 EWC-ALU-010.000-008.000 — Article number: 4417-125100-M20583 — Weight: 35,0 — d1: 10 mm — d2: 8 mm — Delivery time: 10 Days — Price/piece: 58,20 €
• RBC 0025 EWC-ALU-010.000-010.000 — Article number: 4417-125100-010.00 — Weight: 35,0 — d1: 10 mm — d2: 10 mm — Delivery time: 10 Days — Price/piece: 58,20 €
• RBC 0030 EWC-ALU-008.000-008.000 — Article number: 4417-130100-008.00 — Weight: 60,0 — d1: 8 mm — d2: 8 mm — Delivery time: 10 Days — Price/piece: 69,30 €
• RBC 0030 EWC-ALU-010.000-008.000 — Article number: 4417-130100-M20583 — Weight: 60,0 — d1: 10 mm — d2: 8 mm — Delivery time: 10 Days — Price/piece: 69,30 €
• RBC 0030 EWC-ALU-010.000-010.000 — Article number: 4417-130100-010.00 — Weight: 60,0 — d1: 10 mm — d2: 10 mm — Delivery time: 10 Days — Price/piece: 69,30 €
• RBC 0030 EWC-ALU-012.000-008.000 — Article number: 4417-130100-M20594 — Weight: 60,0 — d1: 12 mm — d2: 8 mm — Delivery time: 10 Days — Price/piece: 69,30 €
• RBC 0030 EWC-ALU-012.000-010.000 — Article number: 4417-130100-M20598 — Weight: 60,0 — d1: 12 mm — d2: 10 mm — Delivery time: 10 Days — Price/piece: 69,30 €
• RBC 0030 EWC-ALU-012.000-012.000 — Article number: 4417-130100-012.00 — Weight: 60,0 — d1: 12 mm — d2: 12 mm — Delivery time: 10 Days — Price/piece: 69,30 €

Caractéristiques / spécifications techniques

• Product type: Single beam (single-beam) coupling with clamp
• Material: Aluminium 7075-T6 (material no. 3.4365)
• Function: Backlash-free, angle-synchronous transmission; compensates shaft misalignments
• Intended use: Light applications (e.g., encoders, tachogenerators, spindle drives)
• Available bore combinations (d1 / d2) and article numbers as listed in webshop table above
• Typical delivery time for standard sizes: 10 Days (some larger sizes: on request)
