Plunger pump RHP series

oilelectricstationary

High Pressure Plunger Pump The RONO high pressure plunger pump is a triplex piston pump and is used to convey various edible fat products through multipurpose process lines. The pump cylinder is separated into three chambers in which the plungers are moving for gentle transfer of the product. Suction and discharge side of each plunger are equipped with special dimensioned pump valves to ensure the highest volumetric efficiency. All safety related control elements like the stainless steel pressure relief valve, the pressure transmitter with switch and oil pressure safety switch are of course included. The pump is designed to always maintain a stable and smooth product flow which is the basis for the best final result and a superior product quality. The capacity of the pump can be easily adjusted by a frequency converter easily and allows a digital process control. The RONO high pressure pump is built in accordance with the highest demands of the food industry and meets all CIP cleaning requirements to ensure the best performance and hygienic standards. Types & Variations Capacities The high pressure plunger pump is available in different capacities, starting from 600 ℓ/h up to 15.000 ℓ/h Available valves Depending on your specific product properties you can choose between poppet valves and ball valves. Modular System This applies for all pump components and allows an easy replacement of various parts.
