Pneumatic press E-ROTEX PRO IND

heat transferfor the textile industryrotating table

Short description
The fully automatic E-ROTEX AIR PRO pneumatic swing heat press is engineered for medium-volume production of flex and screen printing transfers, textile and rigid-substrate sublimation, DTG pre-treatment drying and laser transfer, providing ergonomic operation and fast throughput.

Included

• Nomex® platen cover 40x50 cm included

Strengths

• Auto-open, auto-close and auto-swing functionality
• High heating power suitable for DTG pre-treatment drying
• Quick-change platens for rapid job changeover
• T-shirts can be loaded from front or rear of the platen
• Optimized preheat time
• Designed and manufactured in France
• 2-year machine warranty; 10-year warranty on heating elements

Electronics

• Controls: time, temperature, preheating time
• 10 saved recipes (time/temperature/substrate)
• Adaptive regulation per application (sublimation, textile, DTG)
• Eco mode and standby mode
• Double pieces counter

Data sheet
Type: Pneumatic
Operation: Swing - Rotating plate
Platen size: 40x50 cm / 16x20 in
Max thickness: 17 mm
Weight: 81 Kg / 179 lbs
Pressure: 400 g/cm²
Maximum temperature: 220 °C / 429 °F
Power: 2200 W
Power supply: 240 V single-phase + neutral + earth
Amperage: 10 A
Applications: ChromaLuxe, Flex, Direct to Garment, Pretreatment, Sublimation (textile & rigid substrate), Screen Printing, Laser Transfer
Dimensions: 621x847x572 mm / 24x33x22 in

Technical specifications

• Type: Pneumatic
• Operation: Swing - Rotating plate
• Standard platen: 40x50 cm (16x20 in)
• Maximum printable thickness: 17 mm
• Machine weight: 81 kg (179 lbs)
• Operating pressure: 400 g/cm²
• Maximum temperature: 220 °C (429 °F)
• Electrical power: 2200 W
• Supply: 240 V single-phase + neutral + earth
• Rated current: 10 A
• Included platen cover: Nomex® 40x50 cm
• Applications: ChromaLuxe, flex, DTG, pretreatment, sublimation (textile & rigid), screen printing, laser transfer
• Electronics: time, temperature, preheating time, 10 saved recipes, adaptive regulation, Eco and standby modes, double pieces counter
• Quick-change platens; auto-open/auto-close/auto-swing
• Designed and manufactured in France
• Warranty: 2 years on machine; 10 years on heating elements
