Manual press ROTEX

heat transferfor textilescompact

Short description
ROTEX manual swing heat press with a single 40x50 cm platen, designed as an entry-level professional solution for transfer production. Compact, easy to operate and suitable for sublimation on textiles and rigid substrates, laser transfer and conventional transfer media.

Key features

• manual swing
• even heat and pressure distribution
• single platen 40x50 cm (16x20")
• robust frame
• suitable for laser transfer and sublimation on textile and rigid materials
• ideal for small productions

Electronics

• precise, fast PID temperature control for a wide range of transfer products
• compatible with flex, flock, sublimation and screen-print transfers
• advanced electronic controls
• double timer (main + preheating)
• 2 parts counters
• 3 configurable programs
• energy-saving mode
• stop cycle function
• timer range: 0 to 600 s (precision +/- 1%)
• temperature range: 15 to 220 °C (precision +/- 1%)
• heating time 15 → 180 °C: 12 min

Data sheet (table)
Type: Manual
Operation: Swing - Rotating Plate
Platen size: 40x50 cm / 16x20 "
Max thickness: 15 mm
Weight: 61 Kg / 134 lbs
Pressure: 590 g/cm²
°C / °F Max: 220 °C / 429 °F
Power: 2200W
Power supply: 240 V Single-phase + Neutral + Ground
Amperage: 10A
Applications: Flex, Direct to Garment, Pretreatment, Sublimation Rigid Substrate, Textile Sublimation, Laser Transfer, Screen Printing
Dimension: 969x990x453 mm / 38x39x18 "

Technical specifications

• Type: Manual
• Operation: Swing - Rotating Plate
• Platen size: 40x50 cm / 16x20 "
• Max thickness: 15 mm
• Weight: 61 Kg / 134 lbs
• Pressure: 590 g/cm²
• Max temperature: 220 °C / 429 °F
• Power: 2200 W
• Power supply: 240 V Single-phase + Neutral + Ground
• Amperage: 10 A
• Timer range: 0–600 s (precision +/- 1%)
• Temperature control range: 15–220 °C (precision +/- 1%)
• Heating time (15→180 °C): 12 minutes
• Applications: Flex, Direct to Garment, Pretreatment, Sublimation (textile & rigid), Laser Transfer, Screen Printing
• Overall dimensions: 969 x 990 x 453 mm / 38 x 39 x 18 "
