Pneumatic press E-ROTEX AIR PRO

rotating tablefully-automaticwith front loading/unloading

Overview
The full-automatic e-ROTEX AIR PRO is designed for medium-volume flex and screen printing transfer applications, textile and rigid-substrate sublimation, DTG and laser printing, providing optimized operator comfort. Nomex® cover 40x50 cm included.

Included

• Nomex® cover 40x50 cm included

Strengths

• Auto-open, auto-close and auto-swing
• High heating power for DTG pre-treatment drying
• Quick-change platens
• T-shirts threaded from front or rear of platen
• Optimized pre-heat time
• Designed and manufactured in France
• Two-year machine warranty
• Ten-year warranty on heating elements

Electronics

• Time
• Temperature
• Preheating time
• 10 recipes time/temperature/substrate
• Adaptive regulation depending on the application (sublimation, textile, DTG)
• Eco mode
• Standby mode
• Double pieces counter

Applications

• ChromaLuxe
• Flex
• Direct to Garment (DTG)
• Pretreatment
• Sublimation Rigid Substrate
• Textile Sublimation
• Screen Printing
• Laser Transfer

Data sheet (table)
Type: Pneumatic
Operation: Swing - Rotating Plate
Platen size: 40x50 cm / 16x20 "
Max thickness: 17 mm
Weight: 81 Kg / 179 lbs
Pressure: 400 g/cm²
°C / °F Max: 220 °C / 429 °F
Power: 2200W
Power supply: 240 V Single-phase + Neutral + Ground
Amperage: 10A
Dimension: 621x847x572 mm / 24x33x22 "

Technical characteristics / specifications

• Type: Pneumatic
• Operation: Swing - Rotating Plate
• Platen size: 40x50 cm / 16x20 "
• Max thickness: 17 mm
• Weight: 81 Kg / 179 lbs
• Pressure: 400 g/cm²
• Maximum temperature: 220 °C / 429 °F
• Power: 2200W
• Power supply: 240 V Single-phase + Neutral + Ground
• Amperage: 10A
• Applications: ChromaLuxe, Flex, Direct to Garment (DTG), Pretreatment, Sublimation Rigid Substrate, Textile Sublimation, Screen Printing, Laser Transfer
• Included: Nomex® cover 40x50 cm
• Electronics features: Time, Temperature, Preheating time, 10 recipes (time/temperature/substrate), Adaptive regulation, Eco mode, Standby mode, Double pieces counter
• Warranty: 2-year machine warranty; 10-year warranty on heating elements
