Single-axis inclinometer HCA516T

RS-485RS-422TTL

Product Overview
HCA516T is a high-precision single-axis digital inclinometer designed for industrial tilt measurement with selectable ranges and multiple output interfaces.

• Single-axis inclinometer (X or XY option)
• Measure range: ±1° up to ±90° (selectable)
• Wide supply voltage: 9–36 V
• Operating temperature: -40 to +85 °C
• Resolution: 0.001°
• High anti-vibration and shock resistance
• Protection class: IP67

Product Description
HCA516T integrates a high-precision 16-bit differential A/D converter and multiple filtering algorithms to deliver stable, repeatable tilt measurements. The device provides optional interface outputs (RS485 / RS232 / RS422 / TTL / CAN / MODBUS) and supports temperature-based drift compensation via a built-in digital temperature sensor. Output frequency response is configurable up to 100 Hz (standard options to 50 Hz). The robust industrial design and wide temperature tolerance make the unit suitable for harsh control environments and long-term deployment.

Scope of application

• Tilt- and orientation-based positioning
• Ship navigation attitude measurement
• Shield pipe jacking monitoring
• Rail locomotive inclination monitoring
• Construction machinery tilt measurement
• Geotechnical and geological tilt monitoring
• Oil drilling attitude sensing
• Radar and vehicle platform leveling
• Underground drilling rig attitude/navigation

Technical Data (summary)
Measure range: ±10° / ±30° / ±60° / ±90° (selectable)
Measure axis: X / XY option
Resolution: 0.001°
Measure accuracy (@25°C): 0.005° / 0.01° / 0.02° / 0.05° (depending on range)
Long term stability: 0.01° / 0.02° / 0.05° / 0.08°
Zero temp. coefficient (-40~85°C): ±0.002 °/°C
Sensitivity temp-coeff.: ≤50 ppm/°C (≤100 ppm/°C for largest range)
Power on time: 0.5 s
Response time: 0.02 s
Response frequency: 5 Hz, 15 Hz, 35 Hz, 50 Hz (selectable); up to 100 Hz customizable
Output signal: RS232 / RS485 / RS422 / TTL / CAN / MODBUS
EMC: According to EN61000 and GBT17626
MTBF: ≥50000 hours
Insulation resistance: ≥100 MΩ
Shockproof: 100 g @ 11 ms, 3 axial directions (half sinusoid)
Anti-vibration: 10 grms, 10–1000 Hz
Protection grade: IP67
Cables: Standard 1 m wear-resistant, wide-temperature, shielded cable 4 × 0.4 mm²; aviation connector option
Weight: ≤210 g (without cable)

Electronic characteristics (summary)
Supply voltage (standard): 9 V (min) — 12 / 24 V (standard) — 36 V (max)
Working current (no load): 50 mA
Operating temperature: -40 ~ +85 °C
Storage temperature: -40 ~ +85 °C

Dimensions
Shell size: L90 × W59.7 × H34 mm
Installation size: L79 × W29 × H6 mm
Mounting screws: 3 × M4

Model features / specifications

• HCA high-precision series
• Single-axis measurement with X or XY options
• Selectable ranges up to ±90°
• Resolution 0.001° and configurable accuracy classes
• Temperature drift compensation with onboard sensor
• Multiple output interfaces and communication protocols
• Response frequency options up to 50 Hz standard, 100 Hz available
• Industrial-grade IP67 enclosure with shock and vibration resistance
• Wide supply voltage 9–36 V
• Compact and lightweight (≤210 g without cable)
