Single-axis inclinometer HCA series

digitalCANanti-vibration

Short features

• Single-axis inclinometer
• Measure range: ±1° to ±90° (selectable)
• Resolution: 0.001°
• Wide supply voltage: 9–36 V
• Operating temperature: -40 to +85 °C
• High shock and vibration tolerance; IP67 protection
• CAN 2.0A output; configurable output rates

Product description
RION HCA516T/HCA526T-CAN2.0A is a high-accuracy single-axis inclinometer designed for industrial applications. The unit integrates a high-precision 16-bit differential A/D converter and five-stage filtering algorithms to deliver stable angle measurements relative to horizontal (tilt and pitch). An internal high-precision digital temperature sensor enables temperature-drift compensation; temperature output is optional. The device offers configurable CAN2.0A output and a frequency response up to 100 Hz (higher response customizable). It is built for reliable operation in harsh environments and supports extended industrial use.

Scope of application

• Railway locomotive monitoring
• Inclination measurement on construction machinery
• Geological tilt monitoring
• Oil drilling equipment
• Radar vehicle platform detection
• Underground drilling rig attitude/navigation
• Orientation measurement based on inclination
• Ship navigation attitude measurement
• Shield pipe jacking applications

Technical data (excerpt)

• Measurement axis: XY; selectable ranges ±1° to ±90°
• Resolution: 0.001°; Accuracy @25 °C: 0.005° (smaller range), 0.01° (larger range)
• Long-term stability: 0.01° / 0.02° depending on range
• Zero temp. coefficient (-40 to 85 °C): ±0.002 °/°C; Sensitivity temp. coeff.: ≤50 ppm/°C
• Power-on time: 0.5 s; Response time: 0.02 s
• Output rates (configurable): 5 Hz, 15 Hz, 35 Hz, 50 Hz; Output interface: CAN2.0A
• EMC: complies with EN61000 and GBT17626; MTBF ≥ 50,000 hours
• Insulation resistance ≥ 100 MΩ; Shock: 100 g @11 ms (half-sine); Vibration: 10 grms, 10–1000 Hz
• Protection class: IP67; Standard cable: 1 m shielded 4×0.4 mm² with aviation connector; Weight ≤ 210 g (without cable)

Dimensions

• Shell size: L90 × W59.7 × H34 mm
• Installation size: L79 × W29 × H6 mm
• Mounting: 3 × M4 screws

Electronic characteristics (excerpt)

• Supply voltage: 9–36 V (standard 12/24 V)
• Working current (no load): ~50 mA
• Operating temperature: -40 to +85 °C; Storage temperature: -40 to +85 °C

Technical specifications

• Model series: HCA516T / HCA526T
• Type: CAN-bus output tilt sensor (single-axis inclinometer)
• Measurement axis: XY; Measurement ranges: ±1° to ±90° (selectable)
• Resolution: 0.001°; Accuracy and stability as above
• Output: CAN2.0A; Data rates configurable up to 50 Hz (response up to 100 Hz customizable)
• Power supply: 9–36 V; Protection: IP67; Shock/vibration ratings per technical data
• Cable: standard 1 m shielded cable 4×0.4 mm² with aviation connector
• Weight and mounting as listed in Dimensions
