Double-head EDM HPS-1470IIdie sinkinghigh-accuracyhigh-speed
Add to favorites
Compare this product
Characteristics
- Type
- die sinking
- Other characteristics
- high-accuracy, for mold manufacturing, high-speed, flexible, double-head, for metalworking tools, for micro-machining, high-productivity
- X travel
850 mm
(33.46 in)- Y travel
700 mm
(27.56 in)- Z travel
450 mm
(17.72 in)
Description
MODEL: HPS-1470II
X/Y/Z working stroke 850 / 700 / 450mm
Working oil tank volume 2400×1340×700mm(L×W×H)
Workbench specifications 1500×800mm(L×W)
High-Gloss Mirror Circuit (Best Surface Finish) 0.1Ra
Max. Machining Speed 750mm3/min
Max. Machining Current 75A(Optional 100A)
Min. Electrode loss 0.1%
Distance from electrode head to table 550-1000mm
Max. electrode load 200KG
Max. worktable load capacity 4000KG
Total Net weight (including oil tank) 10000KG
Overall Size (L×W×H) 3020×2900 ×3190mm
Positioning accuracy 5um
Repeat positioning accuracy 2um
X/Y/Z working stroke 850 / 700 / 450mm
Working oil tank volume 2400×1340×700mm(L×W×H)
Workbench specifications 1500×800mm(L×W)
High-Gloss Mirror Circuit (Best Surface Finish) 0.1Ra
Max. Machining Speed 750mm3/min
Max. Machining Current 75A(Optional 100A)
Min. Electrode loss 0.1%
Distance from electrode head to table 550-1000mm
Max. electrode load 200KG
Max. worktable load capacity 4000KG
Total Net weight (including oil tank) 10000KG
Overall Size (L×W×H) 3020×2900 ×3190mm
Positioning accuracy 5um
Repeat positioning accuracy 2um
