Plug valve M9 series pneumatically-operatedcontrolflange
Add to favorites
Compare this product
Characteristics
- Type
- plug
- Operation
- pneumatically-operated
- Function
- control
- Body
- flange, cast iron
- Number of channels
- 2-way
- Associated function
- balancing
- DN
Min.: 125 mm
(4.921 in)Max.: 200 mm
(7.874 in)- Pressure
16 bar, 25 bar, 40 bar
(232.1 psi, 362.6 psi, 580.2 psi)- Temperature
Min.: -10 °C
(14 °F)Max.: 205 °C
(401 °F)
Description
DESCRIPTION
• 2-way control valve with flanged connection PN16-25-40
• Body Nodular cast iron GGG40/3 or AISI316
• Seats in stainless steel on or in the body
• Stem seals PTFE- PTFE+ FPM- graphite Self-adjusting
• Plug standard EQP =% (3) in stainless steel with plastic insert. DN125-150- and 200 only metal-metal
• Standard working temperature -10°C up to max 205°C
ACCESSOIRIES
• Converter turns electric signal into a pneumatic signal
• Analogical positioner, also Atex
OPTIONS
• Connections according to ANSI150-ANSI300-JIS 10K- JIS 20K-JIS 40K.
• Lineair plug
• Versions for higher temperatures up to 400°C
• Flow dividers, Balancing cage
