Tractor-mounted salt spreader SyreN

Benefits

• Up to 70% reduction in nitrogen losses when acidification is applied correctly
• Additional sulfur fertilization and mobilization of phosphate for improved nutrient availability
• Higher effective working width with dribble hose or trailing shoe, fewer lanes and reduced crop damage
• Reduced odours during and after spreading

Overview
SyreN is a liquid manure acidification system engineered for front mounting on tractors and for attachment to new or used slurry spreading units. It acidifies slurry during application to limit ammonia emissions, reduce nitrogen loss and improve nutrient use efficiency. The system integrates into standard machine communications and is designed for straightforward operation and maintenance.

How it works
Sulfuric acid is dosed into the slurry in a dedicated mixing chamber located directly in front of the linkage. A continuous pH meter controls acid dosing to reach the operator-selected target pH (typically around pH 6). Acid addition causes foaming and volume expansion, which is why acidification is performed during spreading rather than inside the tank. All components in contact with acid, from the front tank to the mixing chamber, are acid-proof. SyreN is compatible with dribble hose and trailing shoe distributors, which maximizes working width and reduces the number of vehicle lanes.

Safety

• Drip-free coupling for IBC tank replacement to avoid contact with sulfuric acid
• Integrated storage compartment with personal protective equipment (gloves, apron and face shield)
• Two-part rinsing water tank for on-site flushing after application
• System layout and procedures designed to prevent user contact with acid during assembly and operation

Additional information
The acid tank is positioned on the tractor front hydraulics to optimize weight distribution and to allow easy IBC replacement. Controls offer intuitive operation and can be combined with existing communication elements. The chemical reaction during acidification reduces odours and supports compliance with fertilizer regulation requirements.

Distribution
Vogelsang has exclusive rights for the following countries: Germany, the Netherlands, Belgium, Luxembourg, France, Austria, Switzerland, Poland, Czech Republic and Slovakia.

Technical specifications

• Commercial name / model: SyreN
• Acid type: sulfuric acid (used for acidification during spreading)
• Typical target pH on application: approx. 6 (operator-selectable)
• Reduction in nitrogen losses: up to 70% when applied correctly
• Application method: acidification during spreading via dribble hose or trailing shoe
• Mixing: dedicated mixing chamber located directly in front of linkage
• Control: continuous pH meter regulates acid dosing
• Material: all acid-contact parts are acid-proof
• Mounting: front-mounted acid tank (tractor front hydraulics) with IBC replacement capability
• Safety features: drip-free coupling for tank change, integrated PPE storage, two-part rinsing water tank
• Operational note: acidification causes foaming and volume increase—cannot be performed earlier in tank
• Benefits: reduced odour, improved nutrient use efficiency, additional sulfur fertilization, phosphate mobilization, increased working width, reduced lanes and lower fuel/power consumption
