Liquids spiral distributor ECL

continuous-motionrotationalrotary

Overview
The compact ExaCut ECL uses rotor cutting technology to cut and distribute liquid manure precisely and evenly. Steady rotor movement ensures smooth operation while an integrated heavy-material separator protects downstream spreading components. The unit processes large volumes when fitted with hoses up to DN60 and distributes manure uniformly to the outlets.

Key features

• Rotor technology for precise cutting and even distribution
• Self-adjusting, self-sharpening cutting system
• Compact housing with smooth running characteristics
• Multiple model variants for flexible configurations
• Integrated heavy-material (foreign matter) separator as standard
• Effective cutting performance with low-wear operation

Performance and design details
The ExaCut ECL delivers even distribution to between 20 and 48 outlets depending on the selected model. It supports hose diameters up to DN60 and, thanks to its compact design, is suitable where transport width must be limited (transport width approx. 3 m). Balanced cutting-ring geometry combined with a harmonized cutter and optimized material selection provide long service life and reduced maintenance requirements.

Applications
Typical uses include dribble-hose booms and trailing-shoe linkages. Because of its compact footprint and distribution capacity, the ExaCut ECL is suitable for decentralized installations up to a working width of approximately 36 m and for a wide range of spreading-system configurations.

Technical specifications

• Model name: ExaCut ECL
• Distribution outlets: 20 to 48 (depending on model)
• Maximum hose diameter supported: up to DN60
• Working width (typical, depending on configuration): up to approx. 36 m
• Transport width: approx. 3 m (compact design)
• Cutting system: self-adjusting, self-sharpening rotor and cutting-ring geometry
• Integrated heavy-material / foreign-matter separator: standard
• Typical applications: dribble-hose booms, trailing-shoe linkages
• Design focus: precise distribution, smooth operation, long service life, low maintenance
