Radial diaphragm valve Sterillite manualflangeweld
Add to favorites
Compare this product
Characteristics
- Type
- radial diaphragm
- Operation
- manual
- Body
- flange, weld
- Applications
- high-purity, tank bottom
- Other characteristics
- standard, with tri-clamp connection, sterile
- DN
Max.: 3 in
Min.: 0.75 in
- Pressure
Max.: 17 bar
(246.6 psi)Min.: 0 bar
(0 psi)- Temperature
Max.: 204 °C
(399 °F)Min.: -51 °C
(-60 °F)- Flow rate
Max.: 1,143 l/min
(301.95 us gal/min)Min.: 60 l/min
(15.85 us gal/min)
Description
Designed specifically to meet the stringent requirements of the bioprocessing industry Weirless Radial diaphragm tank valves offer solutions to the most challenging applications. It is easy to weld our valves truly flush to the bottom of your tank with our heavy‑duty, thick weld flange. There are no gaskets, bolts or seams.
Features and benefits
Features and benefits
Patented radial diaphragm, eliminates entrapment for easy cleaning
Simple Tri-Clamp assembly makes maintenance 80% faster
No readjustment or retightening
Truly flush mount design with no gaskets, bolts or seams
Integrated travel stops
