Diaphragm valve manualsamplingdrain
Add to favorites
Compare this product
Characteristics
- Type
- diaphragm
- Operation
- manual
- Function
- sampling, drain
- Body
- line
- Applications
- clamp
- Associated function
- outlet
- Other characteristics
- ISO, integral
- DN
Max.: 4 in
Min.: 0.5 in
- Pressure
10 bar
(145 psi)- Temperature
Max.: 260 °C
(500 °F)Min.: -51 °C
(-60 °F)- Flow rate
Max.: 643 l/min
(169.86 us gal/min)Min.: 10 l/min
(2.64 us gal/min)
Description
Designed specifically to meet the stringent requirements of the bioprocessing industry Weirless Radial diaphragm tank valves offer solutions to the most challenging applications. It is easy to weld our valves truly flush to the bottom of your tank with our heavy‑duty, thick weld flange. There are no gaskets, bolts or seams.
Features and benefits
For use in situations where sampling, draining, transferring or directing fluid from a line is necessary
Designed to minimize hold-up in point-of-use applications
Completely eliminates any dead legs
Drains completely, because unlike other designs, our valves have no pockets
Eliminates hold up, because the tip of the diaphragm seals on the ID of the line tubing
Flush mount design, simple clamp assembly
CIP/SIP capable for easy, repeatable cleaning and sterilization
