Radial diaphragm valve manualtemperature controlflange
Add to favorites
Compare this product
Characteristics
- Type
- radial diaphragm
- Operation
- manual
- Function
- temperature control
- Body
- flange, weld
- Applications
- clamp, welding
- Other characteristics
- with tri-clamp connection
- DN
Max.: 4 in
Min.: 0.5 in
- Pressure
17 bar
(246.6 psi)- Temperature
Max.: 135 °C
(275 °F)Min.: -51 °C
(-60 °F)- Flow rate
Max.: 272 l/min
(71.85 us gal/min)Min.: 180 l/min
(47.55 us gal/min)
Description
Designed specifically to meet the stringent requirements of the bioprocessing industry Weirless Radial diaphragm tank valves offer solutions to the most challenging applications. It is easy to weld our valves truly flush to the bottom of your tank with our heavy‑duty, thick weld flange. There are no gaskets, bolts or seams.
Features and benefits
Patented radial diaphragm, eliminates entrapment for easy cleaning
Use with freeze tanks or any tank that has a critical temperature control mission
Extended body and diaphragm allows for direct welding of vessel jacket
Simple Tri-Clamp assembly makes maintenance 80 % faster
