Butterfly valve D341H
with handwheelpneumaticelectric

Butterfly valve - D341H - Wenzhou Pioneer Valve Co., Ltd. - with handwheel / pneumatic / electric
Butterfly valve - D341H - Wenzhou Pioneer Valve Co., Ltd. - with handwheel / pneumatic / electric
Add to favorites
Compare this product

Characteristics

Type
butterfly
Operation
with handwheel, pneumatic, electric
Function
flow control
Media
for wastewater, for oil, for liquid food products and beverages, for chemical products, beverage
Body
flange, seat
Applications
for the chemical industry, for the food industry, for refrigeration, for medical applications
Material
EPDM, PTFE, stainless steel, NBR
DN

Min.: 50 mm
(1.969 in)

Max.: 800 mm
(31.496 in)

Pressure

Min.: 10 bar
(145 psi)

Max.: 25 bar
(362.6 psi)

Description

Flanged butterfly valve has simple structure, small in size, light weight and good flow control features.Available soft seal and metal seal for used in different fields such as medicine, paint, environmental protection, refrigeration, oils & fats,brewing, papermaking, biochemical,dailychemicals, food&beverage, water treatment and so on. Seat seal material - NBR, EPDM, PTFE etc Design standard - GB/T 12238, API 609, JIS B2071 Face to face - GB/T 12221, ASME B16.10, JIS B2002 End Connection - GB/T 9113, ASME B16.5, JIS B2211 Inspection and test - GB/T 26480, API 598, JIS B2003 Operation device - Handle, worm gear, signal, pneumatic,electric actuator

Other Wenzhou Pioneer Valve Co., Ltd. products

Butterfly Valve
