Butterfly valve QD641Lw-1pneumaticelectricfor control
Add to favorites
Compare this product
Characteristics
- Type
- butterfly
- Operation
- pneumatic, electric
- Function
- for control
- Media
- for gas
- Body
- flange, seat
- Applications
- for pipelines, for ventilation systems
- Material
- metal
- Associated function
- transfer
- Other characteristics
- high-temperature, low-pressure, flue gas
- DN
Min.: 100 mm
(3.937 in)Max.: 3,000 mm
(118.11 in)- Pressure
Min.: 0.1 bar
(1.5 psi)Max.: 1 bar
(14.5 psi)- Temperature
Min.: -29 °C
(-20 °F)Max.: 1,000 °C
(1,832 °F)
Description
High temperature ventilation butterfly valve operated by pneumatic or electric actuator, with a special designed metal seat keep valve plate to a flat seal without lining structure, thus significantly reduce operating torque. Additional install a radiator between the valve and actuator, avoid the influence of the high temperature possible heat transfer to the actuator.
Widely use for cold and hot flue gas pipeline, that implementa remote automatic control. Especially suitable for a low differential pressure and mass flow pipelines.
Design standard
GB/T 12238, API 609, JIS B2071
Face to face
-
GB/T 12221, ASME B16.10, JIS B2002
End Connection
-
GB/T 9113, ASME B16.5, JIS B2211
Inspection and test
-
GB/T 26480, API 598, JIS B2003
