Piston valve GDQ-J25bpneumaticfor controlshut-off
Add to favorites
Compare this product
Characteristics
- Type
- piston
- Operation
- pneumatic
- Function
- for control, shut-off
- Body
- flange, straight, right-angle
- Applications
- high-vacuum
- Material
- stainless steel, carbon steel
- DN
160 mm
(6.299 in)- Pressure
Min.: 4 bar
(58 psi)Max.: 6 bar
(87 psi)- Temperature
Min.: -30 °C
(-22 °F)Max.: 150 °C
(302 °F)
Description
GDQ pneumatichigh vacuum angle valve is an electro-pneumatic valve controlled for turn on or shut off the vacuum airflow,the applicable media is air and non-corrosive gases.
It has two structures, one is (GDQ-J) angle type and another is (GDQ-S) a tee type within an ISO-KF or flange end pre-pump port.
Can design as customers’ requirement make with straight through type(GDQ-Z), normally the pneumatic cylinder is with a solenoid valve to control the flow direction; the signal feedback device like reed switch isoptionaldevice.
