3.5" SubCompact single-board computer IE32

Intel® Celeron® J6413M.2M.2 Key E

Overview
Winmate IE32 is a 3.5" x86 embedded motherboard powered by the Intel® Celeron® Elkhart Lake N6211 SoC. Designed for compact embedded control, industrial HMI and automation systems, it delivers a small footprint (146 x 102 mm) with industrial-grade components, flexible I/O and M.2 expansion options for SSD and wireless modules.

Key features

• 3.5” form factor (146 mm x 102 mm)
• Intel® Celeron® N6211 processor (Intel® SoC integrated)
• 1 x DDR4 SO-DIMM 3200 MHz, up to 16 GB
• Dual 2.5 Giga LAN (RJ45)
• Support for 1 x SATA III, 3 x COM, 2 x USB 3.2 Gen2x1, 4 x USB 2.0
• M.2 2242 B-Key (SATA III) and M.2 2230 E-Key (Wi‑Fi) slots
• Wide input voltage options and extended operating temperature support

Certifications

• CE
• FCC

Product highlights
Powered by a low‑power Intel® Celeron® N6211, the IE32 balances performance and thermal/power constraints for embedded x86 workloads. Its compact 3.5" footprint integrates multiple high‑speed network interfaces and internal headers to reduce chassis volume in space‑constrained installations.

Detailed specification highlights

• Processor: Intel® Celeron® N6211 (up to 3.0 GHz)
• Memory: 4 GB default; optional 8 GB / 16 GB; DDR4 3200 MHz SO‑DIMM, max. 16 GB
• Storage: 128 GB SSD default; optional 256 GB / 512 GB / 1 TB / 2 TB; 1 x SATA III for 2.5" drive; M.2 2242 B‑Key for SATA III SSD
• Ethernet: 2 x Intel® 2.5 Giga LAN (RJ45)
• Security: TPM 2.0
• OS support (optional): Windows 11 IoT Enterprise, Windows 11 Pro, Windows 10 IoT Enterprise, Linux Ubuntu 22.04
• Wireless: optional via M.2 2230 E‑Key

IO Ports

• USB: 2 x USB 3.2 Gen2x1 Type‑A (external)
• Internal USB headers: 2 x 8‑pin (2x4) for 4 x USB 2.0
• Serial: 1 x external RS232/422/485 (default RS232); internal 2 x 10‑pin headers for RS232
• LAN: 2 x 2.5 Giga LAN RJ45
• Video: LVDS via 40‑pin DF13 (default); optional HDMI 2.0 and optional eDP via 30‑pin DF13
• Expansion: 1 x M.2 2242 B‑Key (SATA III), 1 x M.2 2230 E‑Key (Wi‑Fi)
• SATA: 1 x SATA III; internal 8‑pin (2x4) for SATA power
• Power input: 1 x 12V DC (2.5φ DC jack) and internal 2‑pin header

Internal I/O details

• Power input header: 1 x 2‑pin for 12V DC in
• Power outputs: 3.3V / 5V / 12V via 2‑pin headers
• Display connectors: 40‑pin DF13 (LVDS) and 30‑pin DF13 (eDP optional)
• Backlight: 1 x 7‑pin for panel backlight
• DIDO: 1 x 14‑pin (2x7) digital I/O
• Fan: 1 x 3‑pin for CPU fan; OSD, audio and RTC battery headers included

Mechanical

• Dimension: 146 x 102 mm (3.5” form factor)

Environment

• Operating temperature: 0°C to 60°C
• Storage temperature: -40°C to 70°C
• Operating humidity: 10% to 95% RH, non‑condensing

Power

• Power rating: 12V DC input (default); optional adapters and wide‑range input variants available

Accessories (included / optional)

• Included: Installation guide
• Optional: SATA signal/power cables, COM cable, 2‑port USB cable, 12V 84W adapter, country power cord, CPU heatspreader, membrane, speakers

Product FAQs (summary)

• Intended use: embedded control, industrial HMI and automation systems—select configuration by system requirements (space, interfaces, serviceability)
• Memory support: DDR4 3200 up to 16 GB
• Storage: M.2 2242 B‑Key (SATA III) and optional 2.5" SATA
• Networking: Dual 2.5 Gigabit LAN
• Display & I/O: LVDS default; optional HDMI 2.0 and eDP
• Expansion / wireless: M.2 2230 E‑Key for optional WLAN/BT
• OS: Windows and Linux variants supported; TPM 2.0 available

Technical specifications

• Model: IE32
• CPU: Intel® Celeron® N6211 (up to 3.0 GHz)
• Memory: 1 x DDR4 SO‑DIMM 3200 MHz, max. 16 GB
• Storage: M.2 2242 B‑Key (SATA III), 1 x SATA III (optional 2.5")
• LAN: 2 x 2.5 Giga LAN (RJ45)
• USB: 2 x USB 3.2 Gen2x1 (external) + internal headers for 4 x USB 2.0
• Serial: up to 3 x COM (RS232/422/485 configurable)
• Dimensions: 146 x 102 mm
• Certifications: CE, FCC
