Air valve AV-M series
pneumaticfor controlIP68

Air valve - AV-M series - YUEQING YISEN ELECTRONIC TECHNOLOGY CO.,LTD. - pneumatic / for control / IP68

Add to favorites

Compare this product

Go to the YUEQING YISEN ELECTRONIC TECHNOLOGY CO.,LTD. website for more information

Characteristics

Operation

pneumatic

Function

for control

Media

for air

Body

IP68

Applications

for industrial applications

Material

DN

Min.: 5 mm
(0.197 in)

Max.: 40 mm
(1.575 in)

Temperature

Min.: -40 °C
(-40 °F)

Max.: 125 °C
(257 °F)

Description

Nylon screw plugs Materials: UL approved Nylon PA66(Flammability UL94V-2) IP rating: IP68 Operating temperature: -40℃ to +100 ℃ Color: Black RAL9005 Thread Product code thread outer diameter(mm) thread length(mm) PG7 PG7-PL 12.5 9.5 PG9 PG9-PL 15.2 9.5 PG11 PG11-PL 18.6 10 PG13.5 PG13.5-PL 20.4 11 PG16 PG16-PL 22.5 11 PG21 PG19-PL 28.3 11 PG29 PG21-PPL 37 12 PG36 PG25-PL 47 12 PG42 PG42-PL 54 12 PG48 PG48-PL 59.3 12 M12 X 1.5 M12-PL 12 9.5 M16 X 1.5 M16-PL 16 10 M20 X 1.5 M20-PL 20 11 M22 X 1.5 M22-PL 22 11 M25 X 1.5 M25-PL 25 11 M32 X 1.5 M32-PL 32 11 M40 X 1.5 M40-PL 40 12 M50 X 1.5 M50-PL 50 12 M63 X 1.5 M63-PL 63 12
