ASSEMBLY ROBOTS:
Several models are available for a variety of assembly applications including the unique dual-arm SDA10D robot, the compact HP3 robot and the 7-axis SIA20D robot.
The slim, dual-arm SDA10D robot is strong, quick and agile. It provides “human-like” flexibility with 15 axes of motion (7 axes per arm, plus a single axis for base rotation). Powerful actuator-based design and best-in-class wrist characteristics make the SDA10D robot ideally suited for a wide variety of assembly, part transfer, machine tending, packaging and other handling tasks that formerly could only be done by people.
The compact, high-speed HP3 robot requires minimal installation space. It offers superior performance in small part applications such as assembly, dispensing, packaging, material handling and machine tending.
The SIA20D (Slim In-line Arm) robot features a revolutionary 7-axis design with best-in-class wrist performance characteristics that enables amazing freedom of movement, coupled with the ability to maneuver in very tight areas. Short axis lengths and extreme motion flexibility allow the slim SIA20D manipulator to be positioned out of the normal working area without limiting the motion range of any axis. The agile, versatile SIA20D opens up a wide range of industrial applications to robots and is ideal for assembly, injection molding, inspection, machine tending and a host of other operations.
|
|
|
|
|
|
FANUC Robotics manufactures reliable and performing industrial robots for assembly applications, present in many industries: automotive (OEM and suppliers), metal, machine-tool, wood, electronics…
The FANUC robot range can answer all assembly needs with more than 50 different models, with a payload form 0.5kg to 1350kg and 4 to 6 axes.
All robots run with R-30iA controller, which uses high-performance hardware and the latest control technology to enhance not only robot basic functions, but also many intelligent assembling functions such as:
• Control of up to 40 axes: up to 4 robots can be controlled by a single controller together with 4 additional axes groups. 2 or more robots can work together to perform assembling, screwing, glueing operations
• Integrated vision system to speed-up the installation of vision applications. This enables easy unmanned operation
• Wide range of fieldbus connections to communicate with a complete production line
• Easy backup and restore (PCMCIA, USB)
• Enhanced security and reliability
• Wide choice of software options
|
|
|
|
|
|
Assembly operations with robots can make the process faster, more efficient and more accurate.
Robots, many of them equipped with vision technology to aid in handling, have saved workers from tedious and dull assembly jobs, while increasing production and quality.
With robots, your assembly operations can produce consistent high quality output, 24 hours a day, all year round. They will eliminate downtime, reduce labor costs and provide a high return on your investment.
Challenge, for example, the 15-axis dual-arm MOTOMAN-SDA10 robot with your assembly tasks.
MOTOMAN, the robotic division of Yaskawa Electric Corporation, is one of the world's leading robot manufacturers with more than 200,000 robots installed world-wide.
We provide the widest range of robots, including application dedicated robots for welding, palletising, handling, painting and clean-room applications, as well as turnkey welding systems with the highest possible quality of operations.
Interested in knowing more? Please contact us!
|
|
|
As a robotics pioneer, the KUKA Robot Group is one of the leading suppliers of industrial robotics. KUKA today offers a uniquely wide range of industrial robots and robot systems, covering all common payload categories and robot types. This means that KUKA always offers you the robot that is exactly customized for your application and industry, for example six-axis robots of all sizes, palletizers, gantry robots, cleanroom robots, robots made of stainless steel, heat-resistant robots, SCARA robots or welding robots
|
|
Mechanical Assembly:
Adept Cobra i600
Adept Cobra i800
Adept Cobra PLC600
Adept Cobra PLC800
Adept Cobra s350
Adept Cobra s350 CR/ESD
Adept Cobra s600
Adept Cobra s800
Adept Cobra s800 Inverted
Adept MotionBlox-10 Servo Kit
Adept Python Linear Modules
Adept Viper s1300
Adept Viper s1700
Adept Viper s650
Adept Viper s850
|
|
· From 12 up to 800 kg payload
· Reduced overall dimensions and wide working volume
· Rapidity and flexibility to optimize the cycle time
|
|
Provide high performance in all areas: this principle governs the development of Stäubli solutions, satisfying all requirements. Designed to work in the most hostile environments as well as cleanrooms, Stäubli robots demonstrate their efficacy under all conditions. Wherever speed, compactness, precision
and reliability are demanded, Stäubli has the matching response - whatever the industry sector or the type of application.
|
|
|
|
|
|
FANUC Robotics manufactures reliable and performing industrial robots for assembly applications, present in many industries: automotive (OEM and suppliers), metal, machine-tool, wood, electronics…
The FANUC robot range can answer all assembly needs with more than 50 different models, with a payload form 2 to 1350kg and 4 to 6 axes.
All robots run with R-30iA controller, which uses high-performance hardware and the latest control technology to enhance not only robot basic functions, but also many intelligent assembling functions such as:
• Control of up to 40 axes: up to 4 robots can be controlled by a single controller together with 4 additional axes groups. 2 or more robots can work together to perform assembling, screwing, glueing operations
• Integrated vision system to speed-up the installation of vision applications. This enables easy unmanned operation
• Wide range of fieldbus connections to communicate with a complete production line
• Easy backup and restore (PCMCIA, USB)
• Enhanced security and reliability
• Wide choice of software options
|
|
|
|
|
|
Motoman SIA20 Assembly Robot
Compact, Lean and Powerful Arm
Lean and powerful, Motoman’s new SIA20 (slim, individual arm) robot features a revolutionary 7-axis design with best-in-class wrist performance characteristics that enables amazing freedom of movement, coupled with the ability to maneuver in very tight areas. The compact SIA20 has a 16% smaller footprint than the previous IA20 model, as well as five times faster acceleration for improved cycle times. The agile, versatile SIA20 opens up a wide range of industrial applications to robots and is ideal for assembly, injection molding, inspection, machine tending and a host of other operations.
The SIA20 robot features a 20 kg (44.1 lb) payload, 1,498 mm (59") vertical reach, 910 mm (35.8") horizontal reach and a repeatability of ±0.1 mm (0.004"). It can straighten vertically to take up only one square foot of floorspace and is just 330 mm (13") wide at the widest point.
Short axis lengths and extreme motion flexibility allow the slim manipulator to be positioned out of the normal working area (i.e. floor-, ceiling-, wall-, incline- or machine-mounted) without limiting the motion range of any axis. Mounting the SIA20 robot between two machine tools provides open access to the machines for fixture maintenance, adjustment or testing. Additionally, the operator has clear access to the machine operator station for entering offsets, maintenance or other operations.
|
|
| ... products without technical information |
| |
|
No automation task is like the other. Due to the comprehensive of robots Epson offers you a complete solution out of one hand. On top the Epson options like fieldbus, conveyor tracking, vision and others help you to solve even difficult and demanding automation tasks.
|
|
|
|
|
|
TM Robotics offer a series of SCARA robots from the TH-250 through to the SR-1504. All have unique handling capabilities for varying workloads. The SCARA range can offer robots with arm lengths of 250mm to 1500mm, and workload capacitys from 3kg to 70kg.
Perhaps the most innovative of the Toshiba Machine SCARAs are the TH-250 and TH-350, which provide better accuracy and repeatability than comparable SCARA's, and offer quicker cycle times and faster motion. These new SCARA’s are so precise that they can even be used to good effect in the electronics industry. The TH-250 and TH-350 feature payloads of up to 3kg and repeatability of ?0.01mm. These robots are suited to applications in the handling of small components, such as electrical, mobile phone and camera parts, assembly and test equipment. Other applications that demand similar accuracy are hard disk drive assembly, as well as very high precision work, such as optical lens grinding and watch assembly. Furthermore, the TH-250 and TH-350 allow the user to place electronic components on PCB boards, or even handle the optical ‘pick up’ lenses used in CD and DVD disc drives.
|
|
Motoman YSH850L SCARA Robot
High-Speed SCARA Robots
The Motoman YSH850L 4-axis, SCARA robots offer high speed in a compact form that requires minimal installation space. The YSH850L model features a reach of 850 mm, Z-axis stroke of 340 mm and 20 kg maximum payload. Additional models are available to meet a variety of reach and stroke requirements.
The YS-series robots feature an IP20 rating and offer superior performance in applications such as assembly, part kitting, small part handling, case packing, lab automation, and magnetic media and semiconductor processing.
These robots easily integrate with existing robot applications to expand current automated processes. They are ideal for large, multi-process systems requiring pick-and-place capability.
YS-series robots feature the same NXM100 controller that is used with Motoman's small six-axis robots (HP3M-series and HP6M-series).
|
|
From part assembly to large-scale pallet transfers.
This reliable and easy to use actuator robot is becoming the nucleus for many automated systems. Hirata is proud to offer the Scara robot as a product of our technological knowledge.
|
|
Hirata SCARA Robot AR-S Series
AR-S series are four axes SCARA robots ideally designed for fast and flexible assembly and material handling. AR-S series have been launched as Hirata’s 5th generation SCARA robot with high speed AC servo motor drive, cost effective and enhanced performance.
|
|
From part assembly to large-scale pallet transfers.
This reliable and easy to use actuator robot is becoming the nucleus for many automated systems. Hirata is proud to offer the Scara robot as a product of our technological knowledge.
|
|
Ultra® TT dispensing robots are a cost-effective way to increase throughput and quality by automating repetitive fluid dispensing processes.
These compact tabletop units can be used with all EFD valves and syringe barrels, and combine precise positioning and dispensing functions in a space-saving footprint.
The Ultra TT robots are available with 325mm x 325mm or 525mm x 525mm work envelopes. Closed-loop servo controls provide fast, accurate positioning of the dispense tip, while the integrated time and pressure controls control the operation of the valve or syringe barrel.
|
|
|
|
|
|
WIRING CELLS FOR LIGHTING SECTOR
With 20 year experience in the automation of wiring and assembly of light fittings with linear fluorescent lamps, System Robot Automazione has developed original operative solutions which, with the efficiency of software packages, with friendly programming combined with 6 axis Kawasaki robots, allow short production times, optimal results and cost reduction.
The combination of the robot with an originally designed wiring head permits all the operations necessary for the preparation of the cables to be inserted into the terminals of the components.
Easy “macro” software functions enable all operations just using one program or through one control push-button.
Modular solutions guarantee future production development without important changes on the system.
The product range includes:
-solutions aimed at the automation of the wiring process only
-automatic test stations in the wiring cell to carry out tests on the wired luminaries
-integrated automation systems for the mounting of components
-integrated systems for the positioning and fixing of ballast
-integrated systems for gasketing
-customized solutions
|
|
|
DSTI offers a number of standard & custom union designs that have been used in the robotics industry. These assemblies can be used to transfer air & electrical signal data to & from the rotating gripper.
|
|
|
DSTI offers a number of standard & custom union designs that have been used in the robotics industry. These assemblies can be used to transfer air & electrical signal data to & from the rotating gripper.
|
|
|
|
