The conveyors are based on an aluminium conveyor beam with low friction slide rails guiding a plastic multi-flexing chain. Products to be conveyed travel directly on the conveyor, or on pallets/carriers. Products that are handled have a weight from a few grams up to 30 kg. The chain design permits horizontal as well as vertical change of direction.
The high flexibility and the wide range makes it possible to use the conveyors in both permanent lines as well as in flexible modularised solutions. Solutions based on FlexLink conveyors are used in all major industries.
Significant features are:
- Short time to install and take in use
- Wide standard assortment assures that the solution is well tailored for the application
- High reliability
- Easy to rebuild and reuse
- FDA approved materials for food applications
- ESD protection for electronic and electrical industry
- Capability for clean environments and qualified clean rooms
|
|
FlexLink’s long experience and wide range of pallet systems are unique in the market. Our systems are based on multi flexible plastic chain conveyors with pallets. Standard solutions like locating stations, diverters and elevators together with our range of linear units, frameworks and enclosures, ensures efficient, high quality installations and systems. FlexLink offers both cost efficient perma-lines as well as flexible module based solutions for easy changes in the production.
FlexLink enables you to:
- Produce different products in the same line at the same time by using the pallet as an independent interface
- Minimize the risk for damage of sensitive and fragile products and thereby increase production yield
- Have shorter lead-times with less products through total control of the production flow
The product range covers all industry segments, from hostile environment in the automotive industry to solutions with demands for ESD safety and cleanliness.
|
|
The FlexLink hygienic conveyor was designed to meet the requirements in the dairy, food, and personal products industries with regard to hygiene, safety, speed, and environment. The hygienic conveyor system uses the standard FlexLink plastic chain, traveling in stainless steel beams where the return chain runs in an enclosed bottom profile.
Main features:
- Easy to clean
- High capacity
- Low energy consumption
- Low noise level
|
|
|
HCS designs, manufactures, assembles, and tests conveyors to industry standards, but with the high level of quality and attention to detail that you’ve come to know from the Hartness organization.
|
|
- designed with two, three or more chains
- for transportation of lump materials in horizontal direction
- pallets or technological support plates with transported material may lay directly on chains or on cross bars connected firmly with chain tenon
- the chain (belt) sections in combination with roller modules work as roller-chain (belt) reloading (transfer) units
- roller-chain reloading unit - in transport systems it is integrated in places with requirement of perpendicular connection of consequential lines without any changes of transported load's orientation
- roller-belt reloading unit - it is used for transport of large size lump objects without any change of transport load's orientation
- accumulative roller chain conveyor - enable stopping-down of transported material at requested positions (and working on it) and its accumulation
|
|
Industries of application: Assembly technology, pad and screen printing technology, microelectronics, food industry, medical technology, cosmetics industry Features:
New, highly precise, flexible type series
Vertical use – the empty work carriers run back along the underside of the plant, saving space
Horizontally, as oval – both sides of the plant are useable for assembly
Available in 3 installation sizes: deflection diameter 480mm, 668mm or 1146m
Self-supporting modular design; modules available with or without frame
Choice of distance of work carriers
User-fined number of breakpoints per work carrier
Indexing accuracy better than ±0.04mm
Drive by means of servo axles
Available with or without controls
|
|
|
Using Low Back Pressure (LBP) conveyors, parts ride directly on a densely populated array of plastic rollers. The parts flow freely with very low friction and exert minimal force on adjacent parts.
|
|
TYPICAL SPECIFICATIONS :
- One and two strand systems
- Low friction UHMW chain guide wear strips
- Effective conveying widths up to 18”
- Motors: 1 HP TEFC 230/460/3/60 Or Higher Dependent on loading
- {Washdown, TENV and Explosion Proof options available}
- {All stainless steel construction available}
- {Motor Drives and Controls available}
|
|
Easy-Link® - the modular chain conveyor system
The Easy-Link® - the modular conveyor system has been developed for the transport of single pieces, e.g. cans, bottles and packets but also for the transport of work piece carriers.
The transported goods can be 2.5 times of the width of the conveyor chain.
|
|
mk conveyor technology
A comprehensive, standardised range of belt conveyors, chain and table top chain conveyors as well as roller conveyors.
The configurability of the modules enables them to be adapted to customers' specific requirements and integrated in complex systems. At the same time, the basic principle of optimum standardisation ensures process security, fast availability and reasonable prices.
Chain conveyors:
- Conveyor lengths: 500 to 10000 mm
- Conveyor widths: 200 to 2000 mm
- Conveyor load max.: 200 kg
|
|
O.C.M. is one of the most important producers of high quality handling lines and its first-class product expresses the logic that we have been implementing over the years. Our company strongly believes that the conveyor belt is a fundamental part of a machinery, which improves its availability and reduces its maintenance. O.C.M. proposes a wide range of tailored solutions which are conceived to be used.
Design and construction phases are carried out in our plant, ensuring high standards and fast delivery time.
Analysing with You which solution better suits your needs can represent a good chance for getting in touch with the fantastic applications we offer our clientele.
|
|
M-800 SERIES Modular Rope Belt Conveyor
The new M-800 Series is a modular, stainless steel, powered case conveyor system for medium duty applications. An economic, custom system can be created with straight, inclined, declined and corner sections, with multiple sections slave driven off a main section
|
|
The chassis consists of two (or three) longitudinal beams made from extruded aluminium-alloy, or steel .
Special features
. Speed of load transmission ( in m/min), Axial distance between the chains (in mm), Maximum width (without sensor) (in mm), element length (in m), Height over the chains (in mm), Finish on steel parts...
|
|
|
The Ryson proprietary chain slat arrangement becomes a versatile and flexible conveyor when used outside a spiral conveyor. Only one drive is required for each 250 feet of conveyor, which minimizes the number of transition points required. This also significantly reduces the cost of controls and system integration. The Ryson Chain Slat conveyors can also be configured as an oval shaped spiral, becoming a space efficient dynamic buffer storage device. More details on the Ryson Chain Slat arrangement are available under spiral conveyors.
|
|
|
|
|
|
Monorail system
The monorail system is a special designed conveyor. It is of the chain slat type, incorporating a proprietary low friction guide system. The monorail system is of a strong and modular design. Only one drive is required due to our proprietary low friction guide system. All conveyors are equipped with an automatic chain tensioning device and built-in overload components requiring minimal maintenance. The guide system includes precision low friction steel bearings and the chain is of heavy-duty chrome plated steel construction. The guide rails are made of polyurethane embedded in an extruded aluminium profile. The slats are of moulded reinforced polycarbonate. The slats are overlapping to accommodate small items. The conveyor can be delivered in steel, powder coated in every desired RAL-colour. Other possibilities are galvanized or stainless steel versions.
Features/advantages
Continuous transport
High throughput monorail system with speeds up to 60 m/min
Load capacity 50 kg/m
One electrical drive, giving savings on controls and system integration
Standard equipped with overload protection
Standard equipped with chain control
Overlapping slats
Easy to install
Low maintenance
Low noise level
|
|
Advantages of uni conveyor chains:
- Less downtime due to higher tensile strength
- Longer chain life due to wear resistant materials
- Super low friction material for high speed applications
- Bevel edges reduce tippage with side transfer
- Increased friction with moulded rubber inserts
- Angled grippers allow for smoother transfer, reducing tippage/misaligning
|
|
Sidel table top conveying systems transport empty and filled product containers smoothly, even at high speeds.
They also manage machine and conveyor operation in order to ensure continuous production on your line thanks to their regulation systems built around a modular mechatronic architecture: each program module controls a specific conveying function. Depending on your needs, the automatic conveyor control systems may regulate the link between two machines, a group of conveyors, or your entire packaging line as a single system.
|
|
Since 1960, BWG has supplied conveying systems for hot rolled and cold rolled coils for the steel, stainless steel and non-ferrous metal industries. Hot and cold coils up to aluminum qualities for lithographic applications are reliably and carefully fed into and discharged from the production process.
BWG's sophisticated designs together with a high level of automation guarantee for shortest cycle times, high availability and low maintenance costs.
|
|
The basic facts make VarioFlow, the new chain conveyor system from Rexroth, a compelling new option: It is more economical than other chain conveyor systems and offers substantially better performance.
Extreme load capacity
Its extraordinarily stable chain allows VarioFlow to achieve chain tensile forces of up to 1,250 N. The nearly closed chain surface allows even small components to be conveyed without complication. An extensive range of conveyor modules provides solutions for the most diverse conveying tasks.
Adapts quickly to any task
An outstanding VarioFlow characteristic is easily it adapts to specific tasks. VarioFlow masters even the most difficult layouts where other conveyor systems fail. On-site adaptation to complex applications is a breeze, and usually requires the exchange of just a few components, such as the chain or the slide rails.
|
|
|
|
|
|
The food industry is governed by strict hygienic requirements, making the VarioFlow S chain conveyor system the system of choice in this sector, as it is not only available in an aluminum version but also as a stainless steel variant.
The VarioFlow S chain conveyor system from Rexroth is quickly assembled, easy to clean and nearly maintenance-free. Products are reliably transported on the almost closed chain surface of a flat, static friction, cleated or clamping chain while open profiles ensure easy cleaning. Extended section layouts with a limited number of drives and the innovative, patented curve technology contribute to the cost-effectiveness of the system.
Lateral Guide Program for Chain Conveyor Systems
The chain conveyor system masters even difficult applications, such as a driven roller bridge for linear transitions. This enables secure transport of small parts in the transition area between the drive and the return unit, as well as empty system trips. Pre-assembled components, based on customized planning with CAD software, ensure smooth construction and allow the user to commission the VarioFlow S chain conveyor system within a minimum period of time.
Lateral Guide Program for Chain Conveyor Systems
Rexroth has expanded the comprehensive range of products in the VarioFlow and VarioFlow S chain conveyor systems with a new lateral guide program. It consists of supports, clamping heads, profile rails and profile cover rails, which guide the most varied parts in numerous standard and customized applications
|
|
Very often used for the mechanical components assembly for automotive.
the differents possibilities allows to built the layout that you need.
|
|
Chain or Drag Conveyors are an important cornerstone in the RONCUZZI product range developed from more than one hundred years of experience in bulk solids handling.
In fact, Chain Conveyors are amongst the most widely used conveyor types in many RONCUZZI installations for handling powdery or granular materials.
Thanks to their robust heavy-duty design, RONCUZZI Chain Conveyors meet every user¿s requirements in terms of reliability and durability.
|
|
|
Chain conveyors can be used for conveying pallets, grid boxes and similar Items both crosswise and lengthwise. This optimized conveyor system provides the ultimate in transport quality and availability. Special features include overlapping chain crossovers and easy-to-use chain tensioners.
|
|
Sidel secondary packaging conveying systems have been designed to respond to the diversity of secondary packaging (format, type, materials).
They can handle every kind of secondary packaging: full or empty cases, cardboard boxes, crates, trays, hi-cones and shrink-wrapped multipacks (champagne or petaloid base) with the utmost product care, even for varnished cardboard boxes.
Entirely built from stainless steel for robustness and cleanability, their design has also been focused on reliability by reducing maintenance needs to the minimum.
|
|
Fixed Direction Pallet Handling Conveyors
Air-Chain Accumulation Conveyors
Features:
Can handle virtually any pallet in any orientation
A single motor can power up to 100 ft. of conveyor
Center-mounted transport chain eliminates pallet drift
Quiet operation from chain movement on a glide surface
Technical Data
Weight capacity 350 to 3500 lbs.
Minimum height 18 inches
Speed 40 ft./min.
Air Pressure 30 psig max.
Rollers/Wheels 3 inch diameter on staggered wheel centers are ideal for GMA pallets with the narrow side leading (bottom boards perpendicular to direction of flow)
--------------------------------------------------------------------------------
|
|
The double chains, working in parallel, are used to transport the goods.
Technical Data:
- Frame: extruded aluminium profiles, 200 mm high Traverses and supports made from steel profile
- Chain: 2 Duplex chain 5/8" x 3/8" DIN 8187
- Max. speed: 0,3 m/sec.
- Motor: slip-on gear motor
- Bearings: high quality ball bearings, maintenance-free
- Side guides: galvanized steel pipes
- Support legs: made from steel profiles, height adjustable by thread ± 25 mm
|
|
Chain conveyors to handle multiformat pallets
Mechanical welded frame : steel (painted), stainless or galvanized
2, 3, 4, 5 or 6 chains are available
Conveying height : From 350 mm to 800 mm ± 60 mm
Load by pallet : 2 tonnes maxi (MARCEAU standard)
|
|
|
The flexibility of the uni Flex chains ensures a great mmiber of possibilities for applications in various industries. Most of the uni Flex chains are flexible in several directions and some of them can be used in veiy small curves with turn discs, which makes construction of very compact conveyors possible. The uni Flex chains are suitable for conveying of plastic bottles, cans and cartons in e.g dailies and breweries, but also for conveying of crates and other large items.
|
|
|
|
|
|
7400 SERIES Straight Plastic Chain Specifications:
Belt widths: 152mm to 1524mm
Lengths: 914mm to 25.4m
Load: 90 kg / square meter of belt
Belt speed: 71 meters/min maximum
Frame material is 304 stainless steel
Bearing material is 400 stainless steel
Bearing lubricant is H1 type FDA lubricant
Wear Strip Material is solid UHMW
Welds are continuous TIG
7400 SERIES Curved Plastic Chain Specifications:
Belt widths: 152mm to 914mm
Total Lengths: 914mm – 30m
Load: up to 90 kg / square meter of belt
Belt speed: 45 meters/min maximum
Frame material is 304 stainless steel.
Degree of curves: 15º - 180º
Features & Benefits:
Frame is constructed of continuous TIG welded 304 stainless steel and is designed with no horizontal surfaces for optimum cleaning.
All bearings are 400 stainless steel, filled with H1 FDA lubricant and mounted in cast stainless steel housings for maximum performance in washdown environments.
Solid UHMW wear strips are easily lifted out of the frame without tools to minimize cleaning time.
Belt tracking mechanism is constructed of 304 stainless steel and is externally mounted to the frame with adequate clearances for cleaning. No external threads are used.
|
|
APRON CHAIN CONVEYOR
Technical Characteristics
- Bed in folding profile without retention, 2mm thick
- Acetal chain in different widths (from 82.5 to 304mm )
- Watertight resin bearings
- Return of chain on revolving rollers
- Curve in compact polyethylene profile with greasers
- Driven by sprocket and chain under boot or motor in direct drive
- Stainless steel or stainless steel/painted steel equipment
- Fully modular or transformable conveyors
- Standard equipment available with short delivery times
Function
Enables the transport of unit or packed products with built-in curves and inclinations. It is possible to fit a roller chain onto the conveyor to obtain an accumulation function.
|
|
|
|
