Description
ACP series 2 : The Adixen range of clean pumps
The ACP series design incorporates the Adixen multi-stage Roots pumping concept, extensively field proven. The pumping module of ACP series pumps is optimized for operation without internal lubricant and seals.
ACP series 2 range consists in ACP15, ACP28 and ACP40 models.
Pumping speed range : 15, 28 and 40 m3/h (9, 16.7, 24 CFM)
Each model is available in Standard version and gas purged, G version.
The ACP series pumps bring outstanding benefits to applications requiring high levels of cleanliness and reliability.
|
|
|
|
|
|
V-VTR
Suction capacity 100 – 155 m³/h
Ultimate vacuum 150 mbar (abs.)
Looking at the pumps’ body, the characteristic features that have made the V-VTR, such a success are still there. Access to filter and valves is easily obtained from one side. Wide cooling air inlets and outlets make sure the pump does not overheat – even at high ambient temperatures. The look has been given a face-lift while staying within the dimensions of the parent machines.
The distinct properties of the new generation rotary vanes can be found under the noise insulating housing. A number of parts have been redesigned to achieve a remarkable lowering of machine temperatures: Manifold ribbing of the housing, Optimized routing of cooling air, Suction and pressure chambers are thermally separated in the filter housing, Minimized contact surface of thermoconducting parts.
Advantages:
• Low noise level
• Easy to use and service
• Environmentally friendly
• Safe and reliable
• Robust and economical
• Low maintenance
• Reduced wear
• Reliable even under extreme conditions
• Energy saving
This machine type is also as compressor (V-DTR) and combined vacuum pump with compressor (V-KTR) available.
Typical Applications:
Environmental, Industrial applications, Packaging, Printing, Woodworking
|
|
The Benefits of SIHI dry at a Glance
PERFORMANCE
• Range m160 up to m1000
• Suction Volume:- 160 to 1000 m3/h
• End Pressure < 1 to < 0.01
LOW LIFE CYCLE COSTS
• No need for service liquids:-
- totally dry principle of operation
- no gears for rotor syncronisation
- no waste disposal
• Low energy cost:-
- reduced power consumption
• Wear free:-
- non contacting rotors
- no mechanical shaft seals
- electronic rotor synchronisation
- no rotor coatings
QUIET
• No gear box
ROBUST and RELIABLE
• For wet processes
- vertical, self draining
- no stagnant ares in pump casing
- liquid carry-over/flushing capability
• For tough operating conditions
- optimised rotor clearance
- torque monitoring
- liquid flushing during operation
- cleaning without dismantling pump
• For explosive gases
- low internal gas temperature
- Ex-rating
- explosion proof design
- ATEX certified
• For thermally sensitive substances
- optimum temperature / compression profile
- uniform temperature profile
|
|
Busch-GVT's Dryflo range provides vacuum engineered solutions for the Pharmaceutical, Chemical, Food and Process industries.
. Simple monitoring - No complex electronic controls
. Explosion proof with High Factor of Safety
. Self Cleaning pump prevents deposit build up
. Independent T4 Certification
. ATEX 100 certified
. Handles corrosives
. Handles VOC's and inorganic chemicals
. Flexible design
. Booster Combinations for higher capacities and System
. vacuum
|
|
Innovac 20 SE
Contamination free vacuum
Two models Innovac 20 and 40 are the first in a new family of dry vacuum pumps designed for use with corrosive gases and vapours
|
|
Dry and Oil-Free!
The Ideal Backing Pump for Pfeiffer Vacuum Turbopumps.
Dry and oil-free diaphragm pumps with a pumping speed of 6 to 160 l/min. They are ideally suitable for being used as a backing pump for Pfeiffer Vacuum turbopumps and for integration into compact systems.
|
|
The Edwards iF dry pumps are specifically designed to provide the high gas throughputs and fast pump-down times required by the latest generation of flat panel display (FPD) manufacturing tools. The iF pumps use proven, reliable screw and roots pumping technologies, feature intelligent monitoring and are fully compatible with the FabWorks network system.
iF1800 Dry Pump
The iF1800 is the optimal solution for the demanding load lock pump down requirements of flat panel display process tools.
Building on the proven quality and reliability of Edwards products, the iF1800 delivers improved pumping performance, the capability to achieve shorter load lock cycle times and increased tool throughput.
|
|
|
|
|
|
The EcoDry M incorporates a dry sliding mechanism without the need for oil or hydrocarbons.
Through the further developed and optimised compression processes, the EcoDry M 15/30 attains with three compression stages a base pressure (total) in the low 10-2 mbar range.
Since the EcoDry M 15/20/30 may be operated either vertically (as normally delivered) or horizontally, this pump is highly flexible when it has to be integrated into the customer’s system.
Advantages to the User
Low maintenance, free of oil and bearing lubrication, free of hydrocarbons
Extremely low particle emissions on the intake and exhaust sides
Rugged and most reliable
Low power consumption
Service friendly
Air cooling
Plug & play
Good pumping speed at low base pressure
High water vapour tolerance (gas ballast standard)
No grease lubricated bearings in the vacuum section
Leak tight
Compact size
Runs at 1000/1200 rpm (50/60 Hz mains)
Rugged full cross section exhaust valves
For both horizontal and vertical operation
Typical Applications
Applications in physics
Loadlock chambers
Transfer chambers
Mass spectrometers
Electron microscopes
Lighting
Thinfilm coaters
Freeze drying
Forevacuum pump for dry high-vacuum systems
Pumping of oxygen concentrations over 21 percent by volume upon request
|
|
V-VSI TWISTER
Suction capacity: 100 to 360 m3/h
Vacuum: < 0.1 mbar (abs.)
Screw vacuum pumps are easy to service and durable. They also excel when it comes to high vapor and water tolerance. Noise and vibration levels are remarkably low.
The innovative screw profile not only delivers high efficiency and an end vacuum of less than 0.1 mbar (abs.) but also maximum volume flow at high vacuum.
Advantages:
• Progressive graduation of screw pitch
• Low noise level
• Low temperatures
• Easy to service
• Variable speed available
• Dry, contact free operation
• Oil free exhaust air
• No wear inside compression chamber
• Only service needed is oil change in gearbox and bearings
• Sealing gas is optional
Typical Applications:
Ppackaging, Drying, Coating, Vacuum furnaces and Solar cell manufacturing
|
|
|
Kinney SDV Dry Screw vacuum pumps operate without any sealing liquid in the pumping chamber. Without metal-to-metal contact inside the pumping chamber, wear is greatly reduced.
|
|
|
Engineered Dry Screw vacuum systems incorporate Kinney Dry Screw vacuum pumps into complete vacuum systems with vacuum boosters, custom controls and accessories to combine high pumping speed with deep vacuum levels. Flows range to 10000 CFM (17000 m³/h) with vacuum levels to 10 microns and below.
|
|
An elastomer diaphragm is moved up and down by an eccentric. On the down-stroke it draws the air or gas being handled through the inlet valve. On the up-stroke the diaphragm forces the medium through the exhaust valve and out of the head. The compression chamber is hermetically sealed from the drive mechanism by the diaphragm. The diaphragm pumps transfer, evacuate, and compress completely oil-free.
|
|
Innovac 60
Motor type
Permanent Capacitor with shielded ball race bearings throughtout, enclosed fan. 1400 RPM @ 50Hz
Thermal Protection 140°C
Maximum ambient temperature 40°C
|
|
High Throughput/Portable vacuum for:
- Glove Box
- Desiccator
- Storage Under Vacuum
- Air Sampling
- Material Handling
Features
- Free Air Displacement to 4.6 CFM
- Vacuum to 26 in. Hg, pressure to 10 PSIG
- Oil-free
- Continuous-duty Operation
|
|
|
Their special design with low weight and small dimensions make the UVD units extremely compact and reliable. This is achieved through the direct assembly of rotor on motor shaft and a powerful centrifugal fan for cooling. UVD vacuum pumps are suitable for evacuation of small, closed systems with residual pressure of up to 120 mbar.
|
|
Meet our High Vac Dia-Va®c…… the Highest quality vacuum pumps on the market. You will find the High Vacuum Dia-Vac® pumps to be extremely reliable and quiet with minimal vibration. Available with General Purpose, Explosion proof, Air Driven, TEFC, and DC motor options. Ultimate vacuum to 3 torr (29.8 InHg) in quad head configuration or 10 torr (29.5 InHg) in double head series configuration.
High Vac Diaphragm Pump - UL/CSA Div. I C/D motor (RVA2-FT-EA1 shown here)
|
|
Non Corrosive Duty
- Filtration
- Aspiration
- Desiccation
- Replace water aspirator
- Vacuum Drying
- Chamber Roughing
Features
- Vacuum and Pressure - to 60 Torr (27.6"Hg) and 106 Pascal (100 PSIG)
- Three Sizes - 22 L/min, 34 L/min, 45 L/min
- No Water or Oil
- Vacuum and Pressure Regulators and Guages - simple to adjust and monitor vacuum level and delivery pressure
- Inlet Water Trap - float ball rises to sear off pump from accidental ingestion of water.
- Muffler - quiets pump and fliters discharge air
- Low Cost
|
|
Fossa scroll pumps contain neither lubricating, sealing nor gear oil in the pumping chamber resulting in completely clean oil-free vacuum.
Fossa scroll vacuum pumps are utilised for high vacuum applications that are clean and dry.
Features
* Non-contact and oil-free compression
* No maintenance, no wearing parts
* Low noise levels
* Light weight and compact, therefore easy to transport
Application
Ideal for use in various industries such as Semiconductor, Electronic, Laboratory and Research
|
|
The Seco vacuum or pressure pumps are oil-free pumps with self-lubricating vanes made of special carbon. They are ideal pumps for all industrial applications requiring totally oil-free operation. The Seco Print model is designed for used in Packaging, Print and Paper applications.
Features
* Easy to install
* 100% oil-free air
* Low noise levels
* Extra long-life composite vanes
* Low maintenance
Application
Ideal for use in various industries such as Packaging, Printing & Paper, Food Industry, Wood Industry, Handling, Environmental Technology and many more.
|
|
Quiet, efficient operation
Four-headed design with chemically resistant solid ETFE and PFA heads
Recommended for use with acidic environments such as HCl, TFA, Acetic and Formic Acids as well as organic solvents
Small compact footprint
Easily connects to any SpeedVac system
Comes complete with ANT100 Post Trap for adding trapping and neutralizing solutions
|
|
oilfree piston vacuum pumps guarantee a high service life and a nearly constant suction capacity even after many thousand of operating hours.
An almost vibration free operation is a significant benefit of our oilfree multicellular-vacuum pumps .
|
|
| ... products without technical information |
| |
V-VSI TWISTER
Suction capacity: 100 to 360 m3/h
Vacuum: < 0.1 mbar (abs.)
Screw vacuum pumps are easy to service and durable. They also excel when it comes to high vapor and water tolerance. Noise and vibration levels are remarkably low.
The innovative screw profile not only delivers high efficiency and an end vacuum of less than 0.1 mbar (abs.) but also maximum volume flow at high vacuum.
Advantages:
• Progressive graduation of screw pitch
• Low noise level
• Low temperatures
• Easy to service
• Variable speed available
• Dry, contact free operation
• Oil free exhaust air
• No wear inside compression chamber
• Only service needed is oil change in gearbox and bearings
• Sealing gas is optional
Typical Applications:
Ppackaging, Drying, Coating, Vacuum furnaces and Solar cell manufacturing
|
|
|
Kinney SDV Dry Screw vacuum pumps operate without any sealing liquid in the pumping chamber. Without metal-to-metal contact inside the pumping chamber, wear is greatly reduced.
|
|
|
|
|
|
The EcoDry M incorporates a dry sliding mechanism without the need for oil or hydrocarbons.
Through the further developed and optimised compression processes, the EcoDry M 15/30 attains with three compression stages a base pressure (total) in the low 10-2 mbar range.
Since the EcoDry M 15/20/30 may be operated either vertically (as normally delivered) or horizontally, this pump is highly flexible when it has to be integrated into the customer’s system.
Advantages to the User
Low maintenance, free of oil and bearing lubrication, free of hydrocarbons
Extremely low particle emissions on the intake and exhaust sides
Rugged and most reliable
Low power consumption
Service friendly
Air cooling
Plug & play
Good pumping speed at low base pressure
High water vapour tolerance (gas ballast standard)
No grease lubricated bearings in the vacuum section
Leak tight
Compact size
Runs at 1000/1200 rpm (50/60 Hz mains)
Rugged full cross section exhaust valves
For both horizontal and vertical operation
Typical Applications
Applications in physics
Loadlock chambers
Transfer chambers
Mass spectrometers
Electron microscopes
Lighting
Thinfilm coaters
Freeze drying
Forevacuum pump for dry high-vacuum systems
Pumping of oxygen concentrations over 21 percent by volume upon request
|
|
|
|
