WM4
is a wrapping machine with double rotating arm , equipped with 2 film distribution heads and one single seaming device which comes above the palett .During the wrapping cycle , only the film is in contact with the load .
The capacity of this machine can reach 150 P/H for standard load and 100 P/H in 5 sides wrapping process.
This 5 sides process , different from the top-sheet process save around 20% to 30% of film.
INTERNATIONAL PATENT
|
|
WRAPPING MACHINE TOSA 120
AUTOMATIC PALLET STRETCH WRAPPING MACHINE WITH ROTATING ARM
While the pallet lies on the conveyor, the wrapping cycle is carried out by a rotating arm holding a film-roll. A steady and compact packing is guaranteed for all sorts ot palletized products by a multilayer wrapping made with stretch film. It is particularly suitable for light and unsteady charges. This machine can be installed on any existing packing line and it perfectly meets high production needs.
|
|
Fully Automatic Stretch Wrapper
Special customer benefit:
• Very little space required due to modular construction
• Variable speeds guarantee that all types of product will be optimally
wrapped
• Machine signals and malfunctions are shown on the clear text display
• The Cyklop Power-Eco-Stretch system ensures an optimal film
pre-stretch of 0-360% - precise and reproducible
• Diverse product sizes represent no problem in the product flow. Due
to the option moveable film takeover the permanently changing
product sizes also represent no problems.
|
|
1525CN Automatic :
- Wraps up to 40 loads per hour
- Heavy duty construction
- Pre-stretches fi lm up to 300%
- Installs over existing conveyor or can beprovided with conveyor
- Positive, non-slip V-belt rotation driveFavori
- Allen-Bradley PLC with operator interface
- Octo-Thread carriage allows easy fi lm threading
- Strain gauge fi lm delivery control
- 3-1/2" dia. conveyor rollers on 3-3/4" centers (1500CN model)
|
|
525 Semiautomatic :
- Wraps up to 35 loads per hour
- No weight limits-loads are wrapped on the floor
- Freestanding or column mounted designs
- Heavy duty construction
- Pre-stretches fi lm up to 300%
- Positive, non-slip V-belt rotation drive
- PLC control
- Octo-Thread carriage allows easy film threading
- Strain gauge fi lm delivery control
|
|
WM1
is a wrapping machine with rotating arm , equipped with 1 film distribution head and one single seaming device which comes beside the palett .
The capacity of this machine can reach 80P/H for standard load .
|
|
LOADING SECURING SYSTEMS
PREMIER TECH SYSTEMS provides end-of-line packaging solutions for reliable and efficient securing of pallet loads used for transportation of various products. Maximum flexibility is designed into our systems to offer maximum efficiency and unmatched film economy.
Rotary Arm Stretch Wrapper
LW-400 Series
Fully automatic system designed to apply a mechanically pre-stretched film with tension to a pallet load. Handles all load sizes and weights produced by our palletizing systems. Unique film delivery system allows precise control of the film pre-stretch for reduced film consumption with optimum load stability. Capacities up to 100 loads per hour.
Applications
Bags, bundles, bales and boxes.
|
|
The only compact, high performance rotating arm machine for stretch film pallet wrapping.
Technical features
- Std. conveyor height from ground 500 mm
- Max. arm rotation speed adjustable by frequency changer up to 30 rpm
- Total installed power 4 Kw
- Standard voltage V400+N+T - 50 Hz
- Electric plant and motors protection degree IP 54
- Pneumatic flow 6 bar
- Acceleration/deceleration ramps adjustable by frequency changer
- Spool carriage upwards/downwards speed adjustable by frequency changer
Product dimensions
- Max. pallet size 1100 x 1300 mm
- Min. pallet size 600 x 800 mm
- Std. Pallet height 2200 mm
|
|
Fully automatic stretch wrapping machine.
All manual operations such as film cutting and film clamping are eliminated, which minimizes the unproductive phases of the wrapping cycle.
Possibility of integration into an existing or planned packaging line.
OPTIONS :
- Top pressure plate for load stabilization
- 300% power pre-stretch
- Welding tail group instead of standard film cutting.
- Programming according to needs.
- motorized conveyor
- Automatic top sheet dispenser
|
|
|
|
|
|
Fully automatic pallet stretch wrapping machine with twin rotating arms for stretch wrapping palletized loads with polyethylene stretch film where very high production outputs are required or loads which require an above average amount of film to contain them effectively.
Thanks to the twin rotating arm technology, the stretch wrapping process is performed on a static pallet thus eliminating any risk of product falling from the load during the wrapping process regardless the arm rotation speed.
Every pallet stretch wrapper from Robopac Sistemi can be fitted with a power pre stretch film delivery system which reduces film usage by up to 50% compared with hand wrapping and substantially increases load stability and presentation. Pre stretch ratio adjustable by changing gears or from the control panel.
Helix machines represent the ideal solution for wrapping light, easily deformable, unstable loads and are present in most market segment fields.
Due to the versatile construction of the rotary arm design the Helix range of stretch wrapping machines can be configured to wrap an outstanding range of products both larger and smaller than the standard pallet format.
Helix HS 40/2 is ideal for an output capacity up to 170 loads/h depending on line speed, and the total number of revolutions of film required.
|
|
|
The AV500 model is an-end-of-the-line winding machine with a rotary arm, conceived for medium productions. Because of its new bridge like structure with two columns it can be rapidly installed and added on to other existing lines above any type of conveyor
|
|
Semiautomatic rotating arm stretch-wrapper, with wheel-driven and bridge feame. Specially-designed for wrapping light, unstable and voluminous products, because the load is positioned on the ground and the pallet does not move during wrapping, with stabilizer press and powered pre-stretch.
TECHNICAL DATA
- Max load capacity: unlimited
- Max. load size: mm. 1400 x 1400 x 3000 h
- Inverter to control the arm rotation speed
- Inverter to adjust the carriage speed
- Pallet height-reading photocell
- Powered 200% pre-stretch
- Film reel size: ext. diam. max. 250 mm - int. diam. 75 mm - height 500 mm
- Stops of rotating arm: in programmed position
- Pneumatic stabilizer press
- Power supply: 400 V - 50 Hz
- Installed power: 1,0 Kw
- Machine size: mm. 3500 x 3500 x 4000 h.
- Weight: 600 Kg
|
|
SpiralGrip 310
Signode's SpiralGrip 310 semiautomatic overhead stretch wrapping system can be mounted to a wall, support beam or SpiralGrip floor stand to provide convenient overhead wrapping of light, very heavy, unstable or odd-shaped loads. The SpiralGrip 310 wraps up to 35 loads per hour.
310 FEATURES
Sensor-Stretch film carriage
Prestretches film up to 300% for maximum film economy and superior load stability.
Angled film carriage design
Wraps to within 2" of the floor, enabling the load to be wrapped to the pallet for added security.
Adjustable force-to-load film tension
Securely wraps loads ranging from heavy, unstable pallets to light, fragile loads.
Automatic load height sensing
Film carriage automatically stops ascent once the top of the load is detected.
No loading ramps
Loads sit directly on the floor, thereby simplifying pallet handling.
|
|
|
|
|
|
The Mancon RA 12/10 is a rigid construction Rotating Arm Stretchwrapper for medium speed in continuous end of line production environments. The machine will easily and effectively wrap pallets with palletised goods on them (usually presented inside the machine by conveyors-conveyor included) for transportation. The machine is fitted with a Power Pre-Stretch Film Carriage for cost-effective pallet wrapping and film savings along with increased pallet stability. The machine can automatically apply a mid cycle top sheet for dust or water protection.
Advance controls on the machine enable simple and reliable stretch wrapping sequences and fault finding. The pallet is coneyed into the wrapping area and stopped automatically. The Rotating Arm connected to the 'tilted downwards' (for wrapping lower onto the pallet) Film Carriage circles, and moves up and down applying film to the pallet. At end of cycle the film is pneumatically gripped, cut by a hot wire then brushed onto the pallet. The machine comes with light guards and perimeter fencing as standard. RA 10/12 is CE marked for safety and performance. Full service and spares support.
|
|
|
Where the application circumstances speak for stretch wrapping, Möllers utilises high-quality stretch wrap machines with which the principle of the circular film roll with stationary pallet is used.
|
|
AVR 310
Is structurally designed to be flexible. Its modularity and its easy setting make the machine extremely versatile.
|
|
AVR 310 ATS
It is structurally designed to be flexible. Its modularity and its easy setting make the machine extremely versatile and the top sheet for waterproof cucle complete it .
|
|
- Highly suited to unstable palettes and picking
- Integrated weighing system available as an option
- Rotating arm technology
- Mobile, with small ground dimensions
- Pre-stretched film for high performance and cost effectiveness
- Palettes up to 18m high
- Works with a simple push-button
|
|
ROTOWRAP is the ideal solution for wrapping stretch film around particularly unstable products. Holding the pallet still and stabilizing the product using a rotating arm is a common necessity for many industries. The ROTOWRAP family offers superior-quality products for end-of-line packing technology with machines of excellent design and manufacture that provide fast and efficient pallet wrapping.
ROTOWRAP LP-AS wrapping machines are built following the high standards of all ROBOPAC machines. End-of cycle film gripping, cutting and sealing are fully automatic.
Whether in the self-standing version or the column version, ROTOWRAP LP-AS machines will effectively handle all aspects of fully automated load wrapping. These machines are unequalled for durability, with performance levels at the top of the class.
Rotowrap LP-AS machines are available with FR or PFS carriages.
|
|
