Features
- Constructed of FDA Accepted Materials
- Electro-Polished 316 Stainless Steel Fluid Section
- Bolted Construction with all Stainless Steel Hardware
- All Investment Cast Wetted Parts
Typical Applications - Food processing, cosmetics, pharmaceutical, chemical additives (food grade), paint, and applications requiring quick-disconnect fluid connections
|
|
JABSCO'S PUREFLO 4-piston diaphragm pump is designed to be used in pharmaceutical, biotech, food or cosmetic applications. The design complies with the stringent requirements of these industries.
The pump and controls are mounted in a stainless steel cabinet. The system can be cleaned easily and the simple construction allows safe and easy use.
Typical Examples:
Solutions containing proteins; Suspension of cells
Bacteria, yeast, fungi, mammalian cells
Suspensions containing viruses
Filtration, chromatography
Solutions or suspensions of polymers
Feed pump for centrifuges and separators
Feed pump for filter systems
Ingredients for food and/or cosmetics
|
|
|
The Murzan PI 50 is the only diaphragm pump specifically designed to meet the special requirements of the sanitary industry. High efficiency oil free air valve, maintenance free ball check system or flap check valve and total visual inspection of all wetted parts, give the user safe and efficient transfer of foods, cosmetics and pharmaceuticals - USDA listed, FDA approved, the PI 50 Series is manufactured to meet general 3-A Standards.
|
|
|
The Murzan PO 50 is the only sanitary diaphragm pump specifically designed with the needs of the poultry industry in mind. This pump can easily handle solids up to 6" (15 cm) in diameter or 7" (17 cm) long without damaging the product; suitable for pumping necks, gizzards, livers, hearts, feet, blood, or any other application in a poultry processing plant. The Murzan PO 50 is FDA approved and USDA Meat & Poultry listed.
|
|
| ... products without technical information |
| |
CIP self-priming pump adopts acid-resisting stainless steel (AISI 316) in valve body, which has unique acid and alkali resistance, and comply with sanitary requirements for foods.
As a positive displacement pump, its features are superior to centrifugal pump since it suction liquid mixed with air or foams and even merely air. It is widely used to suction material with liquid level below the pump, For instance in the milking room, it suctions milk from the milk barrel. It can also be used in automatic CIP cleaning system as return flow pump in cleaning tank. The mechanical sealing is the build-in influx type, and the temperature of suctioned materiaI is no higher than 100℃.
|
|
Features:
- Designed for Quick Disassembly for easy cleaning and sterilizing.
- Conforms to 3A Dairy Standards
- Ceramic, Stainless Steel & Teflon Fluid Path
- Resistant to Chemical & Biological Attack
- No Internal Threads or Blind Holes
- Easily Dismantled for Cleaning & Sterilizing
- Can be used with any Q Drive
|
|
Waukesha Cherry-Burrell's traditional "Can-Do Pump." Versatile in application, its reliability has made it the industry standard worldwide for more than 50 years.
- Easy cleaning and disassembly
- Flexible, three-way mounting
- Field interchangeable single and double "O" ring and mechanical seals
- Exclusive, non-galling Waukesha "88" alloy rotors
- 3-A and BISCC approved
- Maximum pressure: 200 psi (13.8 bar)
- Temperature range: -40° F. (-40° C.) to 300° F. (149° C.)
|
|
|
Advanced pump design, ideal for use in the pharmaceutical, cosmetics and food industry. Each sanitary pump can be stripped down in no time for cleaning and/or sterilization. Also available with 3A certification.
|
|
... see all the products in the category
Drum pumps
|
|
|
|
|
The APV W+ Centrifugal Pump
The most reliable pump in the world
The APV W+ pump is based on a unique hydraulic design which combines maximum efficiency with the highest hygiene standards.
Highest Hygiene Standards
* Meets the strict European hygienic standards (EHEDG)
* 3A Versions available
* Designed for both CIP (Cleaning in place) and SIP (Sterilise in place)
* FDA approved elastomers
* AISI 316L product contact parts
Exceptional Performance
* Extremely energy efficient design
* High efficiency electric motor
* Low power consumption
* Very low noise and vibration levels
Easy Maintenance
* Very easy maintenance with minimum downtime
* Easy visual inspection of shaft seal for leaks
Extensive Range
* 17 models, with capacities of 0.2 to 15 bar and 2 to 800 m3/hr
Flexible Design
* Extensive range of optional variants such as WA+ Aseptic version, multistage, WHP+ high pressure, WI+ Inducer version, WE+ Electropolished and many more..
The W+ pump with its flexible design and many variants is the proven solution for hygienic applications in industries such as Dairy, Brewery, Food, Beverage, Pharmaceutical, Personal Care and Chemical.
|
|
Features
With simpIe structure,easy dismount,adjustabIe foot height,vibration-proof device,Iow noises,high efficiency,Iong-term normal operation,easy maintenance,gentle and tender treatment, of materiaIs this sanitary centrifugaI pump series is your ideaI choice.It complies with food sanitary standard and guarantees original taste of your products.
Application
Mainly used in industries such as pharmacy,aIcohol,foodstuff chemicaI and beverage to deliver Iiquid in smaII flow with high pressure and high pressure filtering.
|
|
|
|
|
|
The APV Ws+ Self Priming Pump
Patented, revolutionary pump.
The APV Ws+ pump is based on a unique technology applied exclusively by APV, showing substantial improvements over traditionally designed self-priming pumps.
The Ws+ pump works according to the water ring principle. However unlike traditional self-priming pumps, the WS+ is equipped with an open impeller ensuring a flexible flow range and enabling you to choose a small pump for your task. The self priming effect is obtained by means of an air screw mounted on the pump inlet.
Highest Hygiene Standards
* Meets the strict European hygienic standards (EHEDG)
* 3A Versions available
* Designed for both CIP (Cleaning in place) and SIP (Sterilise in place)
* FDA approved elastomers
* AISI 316L product contact parts
Exceptional Performance
* The Ws+ is equally suitable as a CIP and product pump
* Extremely energy efficient design
* High efficiency electric motor
* Low power consumption
* Very low noise and vibration levels
* Particle friendly design due to open impeller
Easy Maintenance
* Very easy maintenance with minimum downtime
* Easy visual inspection of shaft seal for leaks
The Ws+ pump has been installed in numerous applications all over the world and proven successful in many industries and applications:
Dairies * Breweries * Butter plants * Cheese factories * Wineries * Distilleries * Food factories * Egg plants * Enzymes production * Colourings * Bio-pharma
|
|
The ToP-Flo® name represents the finest in sanitary process equipment. ToP-Flo® pumps have been designed to offer efficient transfer of product over a wide range of head and viscosity conditions. ToP-Flo® pumps are easy to install, clean, and operate.
ToP-Flo® pumps are suitable for use in CIP (clean in place) installations. This feature enables easy self-cleaning with no dismantling or take-down. Sanitizing of all product contact areas is automatic.
All ToP-Flo® pumps are available in standard inlet sizes and outlet sizes. In addition, enlarged inlet sizes are available for special applications.
|
|
Designed for heavy-duty, high-efficiency applications. Provides exceptional corrosion resistance. Impeller and shaft are one piece, which connects directly to motor shaft; eliminating such problems as vibration, short bearing life, high NPSH requirements, high seal maintenance, poor tolerance, and adverse operating conditions.
- 316L stainless steel volute, backplate, impeller and shaft
- Five-bladed impeller with deeper eye for improved inlet
characteristics
- Modular seal design - one size fits all models
- Wide range of seal options, including standard
commercial seals
-Stronge JM-type motor with large bearings and strong
shaft
- Base mounting options available with all sizes
- Temperature range of fluids up to 450° F.
|
|
A range of stainless steel hygienic pumps - TopClean.
TopClean CS (including CS, CSK, CSX)
A range of hygienic centrifugal pumps comprising 26 modular sizes with a flow rate of up to 575 m3/h and a max head of 100 m.
TopClean CSA
A range of hygienic centrifugal pumps according to EHEDG and 3A standards comprising 21 modular sizes with a flow rate of up to 325 m3/h and a max head of 100 m.
TopClean AS
A range of hygienic, self priming liquid ring pumps comprising 7 modular sizes with a flow rate of up to 55 m3/h and a max head of 40 m.
|
|
Series 4 pumps can deliver a maximum flow of 14 GPM (50 LPM), and are capable of serving applications with a maximum head of 21.5 ft. (4.7 m) (49 ft. [15.6 m] when
driven by an air motor). Applications include electronic medical equipment, etching machines, photo processing equipment, hospital thermal blankets and food heating cabinets.
Standard construction is of polypropylene, with options for wetted materials that include Ryton® or Kynar®. Ceramic, Buna N rubber, and Viton® for total chemical
compatibility. Carbon bushings are available.
|
|
Hygienic Pumps
The Hovap series of hygienic pumps has been designed for continuous operation on thin liquids with viscosities of up to 500m Pa.s. such as milk, wine, cream and beer etc. For complete versatility this range can include heating jackets, frequency controllers, flushed seal and is available with unions, plane ends or flanges.
* Favourable NPSH
* EHEDG approved
* Capacity from 55m³/h to 250m³/h
|
|
Construction
- Close-coupled self-priming centrifugal pumps with built-in strainer.
- B-NMP: bronze version.
Applications
- For water circulation in swimming pool filtration systems.
- For clean or slightly dirty water with solids in suspension.
|
|
Model BOGP centrifugal pump is a single centrigugal pump with low flow and high lift, which is specially designed by Bobo company considering the defect that ordinary single centrifugal pump has low flow and low lift. Its special vane structure makes it reach high-lift and low flow simultaneously. It has some features such as high efficiency ,hygiene ,no dead space, easy to clean .Its pump shell., cover and vane are made of high-grade stainless steel 304 or 316 L; the motor is equipped with stainless steel shield; the inner surface adopts mirror polishing, its coarseness is Ra0.28um; its outer casing adopts wiredrawing treatment completely ,beverages etc.
Application :
Mainly used for the liquid delivery that needs low flow high –pressure delivery or high-pressure filter in the fields such as pharmaceutical ,food, chemical ,beverages etc.
|
|
| ... products without technical information |
| |
|
|
|
|
The APV DW Rotary Lobe Pump
The most versatile rotary pump on the market
The APV DW range reflects latest technology in the development of rotary positive displacement pumps. No equivalent pump on the market offers such a wide range of features incorporated in a single pump.
Ultra Hygienic
* Meets the strict European hygienic standards (EHEDG)
* 3A Certified
* Designed for both CIP (Cleaning in place) and SIP (Sterilise in place)
* FDA approved elastomers
* AISI 316L product contact parts
* Completely self drainable when vertically ported
Exceptional Performance
* High volumetric efficiency
* Very low noise and vibration levels
* Low NPSH requirement
* Gentle product handling
* Patented rotor design option means pulse free operation
Easy Maintenance
* Minimum downtime with easy access front loaded mechanical seals.
Extensive Range
* Over 30 models, with capacities of 0 to 30 bar and 3 to 1016 litres/100 revs
* Wide choice of shaft seal type and materials
Flexible Design
* Available with a wide choice of additional options such as Thermal Jackets, Rectangular Inlets, Integral Pressure Relief Valve, Non-galling alloy rotors and much more
The DW pump with its flexible design and many variants is the proven solution for hygienic applications in industries such as Dairy, Brewery, Food, Beverage, Pharmaceutical, Personal Care, Chemical and many more.
|
|
Rotary Lobe Pumps - TopLobe and TopWing
The original design of the rotary lobe pump goes back to the early 40’s and has since then been further developed and improved. Johnson Pump has long experience in rotary lobe pumps. Market knowledge and appreciation of customer needs have been used to improve the existing rotary lobe pump concept with new features and customer benefits.
Rotary lobe pumps are easy to clean and have gentle product handling characteristics. They contain few cavities, which reduces the risk of bacterial growth and makes them particularly suitable for the transport of sensitive fluids – from glue to whole strawberries.
|
|
Universal cam and lobe pump is suitable to tenderly transfer high-viscosity matter or the matter containing particles. It is suitable for hygienic and aseptic place. Tenderly handing matter, slow rotational speed(200~600rpm), adjustable transportation speed, especially suitable for the matter that are susceptible to foaming or may be damaged during high-speed transportation. It is also used as a metering pump. It is suitable for on-the-top CIP cleaning and steam sterilization. Hygienic handling conforms to GMP standard.
Application
Medicines: Pill siziness, syrup, medicine thick fluid, milk shape liquid, proteide
Cosmetics: dyes, alcohol, essential oil
Dairy: whey, cream, milk, sugar liquid
Beverages: alcohol, spirits, beer, wort, ferment powder, fruit juice, beverages with particles
Other: sweet industry, baking industry and chemical industry etc.
|
|
|
|
