Premius
Brilliant print results and high gloss effects with waterless offset printing
and UV technology. High-speed printing on a wide range of media
including DVD, CD, MiniDisc, Optical Business Card and special formats.
The Premius offset printing machine from KBA-Metronic AG helps your business thrive. You get brilliant print quality combined with excellent performance and perfect reproduction of photorealistic images on DVDs, CDs, MiniDiscs and Optical Business Cards from the first piece to the last even on large print runs.
The consistency of print results on the Premius is simply outstanding. Mature, field-proven technology from KBAMetronic is your guarantee of exceptional print quality. Waterless offset printing,
short inking units without ink keys and an efficient four-cylinder print unit design all enhance ease of operation, reliability and availability. UV varnishes can be applied to some or all of the media surface to add a high gloss appearance.
The speeds are equally impressive. You can print up to 7,200 pieces an hour, change printing plates semi-automatically in less than 5 minutes, and there is no need to adjust registration. All of this adds up to short setup times and high machine utilization, even when you are running more than one shift.
KBA-Metronic AG has many years of experience with short inking units that
work without ink keys. Temperature is used to control the color tones which
remain constant across the entire width of the print surface. Many adjustments that are necessary with conventional offset printing such as setting ink keys are not needed on the Premius.
|
|
Cylinder Automatic Pen-rod screen printer
Machine Parameters:
Printing Speed: 4000pcs / hr
Printing Size: ƒÓ8-ƒÓ100mmPrinting Length 25-270mm
Compressed Air: 0.6MPa
Lp Gas: 0.15MPa
Dimension Unit: 1907~1000~1500mm
Test Table: 2000~500~700mm
Power Unit: 380VACC3-PHASEC6.5KVA
Test Table: 220VACC1-PHASEC0.2KVA
ApplicationF
It is a one color automatic colour screen printing machine with fully auto feeding, flame treatment, screen printing, UV curing and loading system. It is fully automatic screen printing machine and perfect for printing one color pen rod, plastic bottles and oval shape products which require very high working capacity. The thansmission structure advantaged designed, so the machine runs stable and to be operated flexibly.
|
|
|
|
|
|
Automatic Glass bottle screen printer
Specifications©U
1. Product Outlook: Ink Cylindrical
2. Printing Size: Max Dia.80mm
3. Printing Length: Max. Length:300mm
4. Working Capactiy: 900pcs/hour
5. Frame Heating Power rate: 2.2W
6. Power Supply: 220V 1-phase 50Hz
7. Air Compressor: 5-7 Bar
8: Total Power Rate: 2.8KW
10: Machine Dimension:2300 ¡Á 1000 ¡Á 1700mm
Advantages:
Products Description: ¡Á Aluminium alloy structure frame;
¡Á Automatic feeding, transportation,screen printing, drying;
¡Á One time loading objects and muti-colour overprint. fit printing objects without orientation point and hole;
¡Á PLC controlling and touch-screen operation technology;
¡Á World famous brand pneumatic part and electron parts;
¡Á High printing efficiency and high printing precision;
S-303 is a fully automatic 3 color glass bottle silk screen printing machines. The major application of this machine is for the printing of beer bottle,drinks bottle and water glass, cup, ceramtic vase etc. The feasure characteristic of this machine is to applies simple solution to solve registration positionaing problem.
Adopt the high temparature glass ink, printed by heating melted glaze. After finsih printing, taking the final step of drying burning process with high temapature stove so as to make the ink completly melting with the substrate. The screen frame is being used recylce. You will be astonished by the printing quality as well as the low printing cost and environmental protection. The Glaze was meted.
|
|
Electrical Fully Automatic Pen-rod cylinder screen printer
Specifications©U
1¡¢Objects diameter£º¦Õ3¡«¦Õ20 mm
2¡¢Objects length£º70¡«180 mm
3¡¢Printing stroke£º 20¡«80 mm
4¡¢Max printing speed£º 6600 pcs/hr
5¡¢Motor wattage£º 4.5kw
6¡¢Net weight£º ¡Ö450kg
7¡¢Outer dimension£º 3200¡Á1120¡Á1520mm.
Advantages©U
¡Á Cleaning screen , adding ink when stopping will not singe objects in drying closet;
¡Á With vacuum function seated (selection ) for precision orientation.
¡Á High speed printing;
¡Á Printing two kinds of diffrent objects meantime is able.
¡Á Installed surface cleaning device;
¡Á Double blade design for high quality coating ink;
¡Á Eletron controlling ensure lower noise;
¡Á Automatic feeding and printing;
¡Á Printing stroke and printing speed is adjustable;
¡ÁTaiwan frequency conversion production installed
¡Á IR or UV drying system online.
|
|
SP-350-FR
SCREEN PRINTING MACHINE
FEATURES
- PLC Controlled, Pneumatically operated
- Flat, Curved and Round Printing
- Linear Bearings for long life
- Aluminum Parts for faster and smoother operation
- Good quality components and Pneumatics
- Simple to operate
- T-Slotted XY & R table for easier and faster registration
- Attractively and appropriately treated with powder coating, Hard Anodising and Electroless Ni.Plating
- Noise less operation with shock absorbers
- All the required adjustment built-in
- Bottle inflation attachment available
- Registration of earlier colour for round articles available
- Fast and easy change over from Flat to Round printing
- Marked Dials & Scales for easier settings
|
|
|
|
|
|
CD-Print
CD, DVD and Blu-ray (BD) printing in photorealistic quality using waterless offset printing and UV technology. Also suitable for small print runs.
CD-Print from KBA-Metronic AG gives manufacturers and service providers in
the CD, DVD and BD sector the efficiency, flexibility and quality differentiation that they need to deliver what customers are looking for. CD-Print is ideal for small to medium print runs. It offers professionals a very efficient professional solution, which novices also find easy to use.
6,000 photorealistic prints per hours, minimal startup waste and fast changeover make CD-Print the superior choice. The system features relatively low operating costs, which are made possible by waterless offset printing using short inking technology, one-man operation and reproducible print runs. Because CD-Print uses UV technology combined with a high-performance drying system, the discs can flow into downstream operations right after printing to avoid unwanted idle time.
CD-Print features a practical compact, modular design. It is designed for
tomorrow’s applications. Two additional print stations for decorative colors can be added to CMYK printing. In addition to the white basic unit which comes as standard equipment, a varnish unit can be supplied as optional equipment which gives the disc an appealing finish.
CD-Print is the ideal partner wherever space, cost and time are crucial
production parameters.
|
|
Machine Parameters:
1.Printing Speed Round: 4000pcs / hr Oval 5000pcs / hr
2.Printing Size: Round Diameter 20-100mm Length 25-270mm
3.Printing Length: Oval Width 25-120mm Length 25-270mm
4.Compressed Air: 0.6MPa
5.Lp Gas:0.15MPa
6.Dimension Unit: 1907~1000~1500mm
7.Test Table: 2000~500~700mm
8.Power Unit 380VACC3-PHASECUnit 6.5KVA
9.Test Table 220VACC1-PHASEC0.2KVA
ApplicationF
This multi-purpose fully-automatic polychromatic screen printer is applicable to print patterns on the surface of cylinders and oval cylindrical bottles. The colors can be either assorted or fixed by connecting a number of machines or separating machines to print so as to meet different customersf needs to the most extent. The updated transmission design features being more stable, easier to switch to bottles of different shapes, and more flexible. Besides, its favorable price ratio will drive the product to be used by more and more small and medium-sized enterprises
|
|
|
|
|
|
Machine Parameter:
1.Printing Speed: 3000-3600pcs/hr
2.Product Printing size Range: Cap's outter size:Ö15-Ö34mm Cap's Height:25-60mm
3.Air Compressor:0.6-0.7MPa 4.Gas Pressure: 0.15MPa
5. Dimension: 300X1900X2900mm 6. Power Supply: 380V 50HZ 7.Power Rate: 6KW
Machine Description:
Design for the round product without the fixed position, mainly printing the soft tubes, caps, circular bottles. Can accurate printing 1-5color and chromatography.
This Machine is one of our newest creative and latest patented design of our fully automatic horizontal type screen printers with conveyors.
Transmission mainly used for high-speed precision intermittent segmentation combined with the standard cam, meanwhile realization of the precise point, to make machine more stable and reliable operation at up the speed to 3,300 pcs / hr. Adopt international PLC control and the setting up of simple and efficient operation of the touch screen, and easily achieve human-machine dialogue, operating comes in handy.UV curing adopts the PRIMARC UV curing system of our agency Company in the United Kingdom, in the event that guarantee the stability and performance of the energy savings, will be even more excellent curing effect.No case has not printing, low-pressure alarm, waste / alarm wrong material, UV overheating alarm monitoring function. Automatic loading and lay off system guarantees the continuity of printing, and avoid as much as possible in the printing process in the printing surface of the trauma of protection for the safe operation of operating personnel.
|
|
|
|
|
|
Specifications©U
1. The max printing thickness: 200 MM
2. Air consumption: 75 Lit/Min
3. Outline size: 1080¡Á850¡Á1280MM
4. The max printing area : 200¡Á250MM
5. Dimension of working table: 250mm¡Á300mm
6. Max printing speed: 1800Pc/Hr£»
7. Max frame dimension: 410¡Á350mm.
8. Stroke of Squeegee: 250mm.
9. Stroke of Table cylinder: 60mm.
10.Max Diameter of Products: 75mm
11.Max length of Products: 300mm.
12.Gross/Net weight£º127kg/90 kg
Advantages©U
1. Controlled by microprocessor easy operation running stably and accurately.
2. 4-digit auto counter built-in.
3. Cast aluminum machine frame,low weight and high intensity,adjust convenient.
4. Separate adjustment of the pad up/down stroke speed.
5. Ink scraper is auto balance keeping in printing.
6. With the function of ink scraping nonstop without printing in order to prevent the ink from drying.
7. Ink cup is turnable and adjustable in vertical and horizontal direction.
8. With super long slide stroke to print large size workpiece.
9. Pneumatic part of the installation of the German FESTO Parts, Separate adjustment speed.
Application Scope:
Suitable for precise printing substrates in Cylindrical, Conical and Oval forms which with smooth curve surface and made of various materials such as metal, plastic, ceramic, glass, wood etc.. Printing objects such as lipstick, cosmetic bottles, scour bottles, drink bottles, pots, oil-filter shell etc..
|
|
6 Colors Offset Printer
4 Colors in 1 line plate to ensure the average printing roller pressure from start to end.
Model: HS-480WD
- Computer to Film system.
- Motor driving conveyor loading/unloading type according to CE required, no moving parts outside.
- Linear indexing printing conveyor table.
- 4 colors in one line plate to ensure the average printing roller pressure from start to end.
- Alternative or combination for screen and offset printing.
- Quick plate change
- Fully compatible integration with ldent code and print label check. (optional)
- Special printing table design, no ink contamination.
- Quick change from CD to DVD printing.
|
|
AUREL Full Automatic Printing line for Cermet potentiometers
Features
• Loading from stack magazine
• Belt transport
• Screen Printer
• Collocator with gripper-head
• Drying furnace
|
|
Panasonic's SP18 high speed screen printing machine is the ultimate solution for lean SMT manufacturing. Our original uni-floating printing method reliably delivers the right amount of solder in the right form - with high-speed snap-off and reduced solder waste.
The SP18's intuitive interface enables the operator to set parameters based on production requirements - making print condition adjustments nearly automatic. Automatic batch teaching of the board and recognition mark functionality further enhance its appeal.
Quick changeover, compatibility with industry standard stencils, and optimal efficiencies will increase your profits and increase your accuracy to world-class levels.
Features & Benefits
Economical solution for lean manufacturing
Intuitive interface - set parameters based on production requirements
Compatible with industry standard stencils
Customizable operator screens support user authority
Quick changeover ensure continual production
Efficient, small footprint
|
|
|
|
|
|
AUREL C2025TL High precision Screen printer
Description
The AUREL Mod. C2025TL is a high precision screen printer for very large areas up to 700x600 mm.
Special table for vacuum hold down of foils and for holes metallization.
Options
• Vacuum table for thin foils hold down
• Holes metallization or holes filling
• Cross Flow head
• Clima controll
• Special automatic handling system
• Proguide vision system
• Automatic stencil cleaning
Technical Features
• Double squeegee head for the use of metal squeegees or rubber squeegees.
• Squeegee drive actuator with DC servomotor and very smooth movement of the printing head.
• Printing mode: Contact, Off Contact, Single Print, Double Print, Print & Flood, Delay after Print.
• High precision and repeatability gor fine pitch printing.
• Motorized squeegee with programmable printing pressure and down-stop.
• X-Y-q adjustment by centesimal micrometers, on the shuttle table.
• Motorized and programmable screen lift movement (Z axis) for the function "slow snap-off" very important on fine line printing.
• PC control with menu programming printing parameters, diagnostic, timer adjustment for delay after print, data storage.
• Screen holder and printing head lift for easy set up and cleaning.
|
|
AUREL VS1520A Screen-stencil printer
AUREL VS1520A Screen-stencil printer for high quality fine-line and fine-pitch printing on Ceramic substrates, LTCC, PWB, WAFERS, GLASS, METAL
Description
The series VS screen-stencil printer uses highly advanced mechanical and electronical solutions to guarantee superior quality in fine-line and fine-pitch printing on Ceramic substrates, LTCC, PWB, WAFERS, GLASS, METAL etc.
The Automatic Vision System ensures resolutions better than 2 microns. All the machine's movements are motorized and programmed by a user friendly menu.
|
|
Suitable for non-deforming material or rigid substrate flat surface printing, such as acrylic sheets, transferring paper, computer keys, stationery, golf ball, etc.
Suitable for non-deforming material or rigid substrate round / conical / oval printing, such as bottles drun, glass, etc.
|
|
High-speed printing with superb accuracy :
Printing accuracy of less than 20 µm
Printing cycle time 7.0 seconds + printing time
2-camera automatic calibration
Easy operation
Within 2 minutes production changeover
Small footprint of 1,1 x 1,285 m
|
|
Close tolerance screen and stencil printing is usually associated with smaller-format substrates and print areas such as used in micro-electronics. In recent times, however, there is a growing need for larger-format applications as used in the medical, solar, display, and flexible electronic circuitry fields.
MTS® Series printers allow better process stability for large areas--in all axes, and with superior results based on your screen making capabilities. Preco’s X-Y-theta camera registration can be equipped with a variety of fiducial recognition techniques, to provide unique repeatable accuracy for all formats.
|
|
|
|
|
|
Function
Large board dimensions, different conveyor modes tor different throughput rates and a new high-speed inspection function - these
are the key product features of the X6. Printing tables with different designs tor different versions allow solder paste printing on partly assembled circuit boards (i.e. components mounted on the opposite side) with formats ot up to 610 x 550 mm. The choice
of the right circuit-board conveying system is determined by the required throughput rate. The single-track system conveys the
circuit-board safely through the printer and requires a handling time of only 12 seconds.
The single-conveyor HSP version with its tripartite conveyor belt shortens this handling time to less than 7 seconds.
The new high-end version of the EKRA 2 1/2-D postprint inspection delivers several images from up to 4 inspection stations every
second, thanks to the use of the latest linear engine drive technology. The use of a larger camera sensor increases the field
of view to 20 x 16 mm without any loss in resolution, ensuring that the 2 1/2-D postprint inspection system delivers consistently better results than the so-called line-scanner solutions and allowing
a thorough analysis of the solder paste printing quality on the basis ot its images.
Standard version with adjustable squeegee pressure and as a VIP head with weight compensation and fine-tuning for the squeegee
power. The automatic stencil-cleaning function also features in the basic version.
|
|
Overview
Discproducer (PP-100) is ideal for a wide range of markets including retail photo centers, photographers, service bureaus, church groups, education and more. It has all the features you need to print and burn up to 100 customized CDs or DVDs at a time. From its vibrant six-color inkjet printing and precision AcuGrip™ robotic arm to its easy-to-use software and unmatched reliability, with the Discproducer you'll get the high quality results you're looking for every time.
Product Features
- 100 disc capacity
- AcuGrip™ technology minimizes two-disc feeding
- Highest quality printing in its class with MicroPiezo technology
- Six individual, high capacity ink cartridges
- Low-ink sensor and LED for each cartridge
- Publishing speeds of up to 30 CDs and 13 DVDs/hour
- Compact, dust-proof rugged construction for top reliability
- Easy-to-use software with label templates
- Economical to operate and maintain
|
|
F.A-1 ( Fully Auto Round Screen Printing Machine)
FA Series are fully automatic Screen Printing machine for round Jobs in various sizes. This Machines is specially for one type of long jobs. It can print on Plastics Bottles, Caps, Filters and So many other round Products. It reduce the labour and Skill persons. We can make the machine as per customer specifications also. UV. Curing or Conventional Dryer is optional.
|
|
APL SAF-7 (Semi Auto Flat Screen Printing Machine)
APL SAF series models are pneumatically operated and available in various sizes. This is a PLC controlled Machine with various features for easy operations of machines. Machine is equipped with Festo cylinders and linear guides X Y Table is given for quick registration. This machine can print on Paper, Plastics, Metal, Glass, Wood, PCB, membranes switch, Advertisement materials, Cloth and so many other flat products.
|
|
