Slider SFX - The all-in-one solution for desktop CNC machining and handling!
Everything you need on just one board:
The stepper motor driver "Slider SFX" integrates all functions needed for a 3 axes desktop cnc machine or a 3 axes handling system. 5 logic inputs for end or reference switches (or tool sensor) and 3 relay outputs are included. If necessary, a 4th axis can be added with an optional cable. The integrated power supply makes it possible to drive the board from a simple transformer or a single voltage switching power supply.
For heavy duty use (environment temperatures up to 70°C) the HT version is available. A CNC machined aluminium housing and a matching switch and connector set are also available.
It was never easier to build up a complete 3 axes stepper motor controller!!
|
|
3 channel stepper motor board '3D-stepdriver'
Features:
* 3 channels (expandable to 4)
* Easy adjustable phase current up to 2,1A per phase (via trimmer)
* Up to 45V supply voltage
* TTL compatible in- and outputs
* connectable to PC printer port or microcontroller
* compatible to common CNC software (PCNC, CNC-profi, DIN-CNC, Mach2, EMC etc.)
* Half- and fullstep mode
* Two different current regulation modes
* Onboard logic for 4 reference/limit-switches and one emergency switch
* Connector for staus LEDs or 4th axis extension
* Adjustable chopper frequency
* 'Smoothing' function for more torque in halfstep mode
* Typical current consumption 250mA (5V part)
* Suitable for both bi- and unipolar stepper motors with minimum 1,6 ohms coil resistance
* Eurosize board (160*100mm)
|
|
|
Power drives for 2 phase steppers and 3 phase steppers in wall mount, DIN rail, 19” Euroformat rack, and open frame versions.
|
|
|
|
|
|
SW1 PROGRAMMABLE STEPPER DRIVES:
The SW1 programmable full digital 2 phase stepper motor drives are suitable for multiform applications with step & direction, velocity analog reference, serial RS232 control, or as CANopen, Half/Full duplex RS422/RS485 slave mode multi axles systems.
The drives can also be used in Stand Alone Mode thanks to the built-in eePLC firmware integrating PLC, Motion, Process and Drive Modules in one device featuring a fast and user friendly method for applications customizing and development. Through the MS Windows eePLC Studio programming environment the user can access the whole functionalities and resources of the device to manage and synchronize the motion module and other drive's resources to any process events.
MAIN FEATURES:
- 140 Vdc, 100 Vac or 230 Vac (no AC mains transformer) power supply
- Modbus (RS232/RS422/RS485) or CANbus (CANopen) control mode of
extended security on board provisions.
- 16 digital inputs, 10 digital outputs, 2 analog inputs, 2 analog outputs
- protections against over/under voltage, over current, over temperature
- working temperature from 0°C to 50°C
- storage temperature from 0°C to 55°C
- humidity: 0 - 90 %,
- protection class: IP20.
LW1 CK & DIR STEPPER DRIVES:
The LW1 microstep drives for 2 phase stepper motors can be managed by means of hardware settings (dip-switches), clock/direction inputs, analogue inputs or start/stop inputs.
MAIN FEATURES:
- supply voltage from 24 to 80 Vdc
- phase current controllable from 1 to 5,5 arms
- step angle till 1/256 and 1/250 with sinusoidal envelopes, inputs and
optoisolated outputs and reduction of the automatic current.
|
|
Stepper motor controller with Nano-Step resolution.
The controller is able to manage 3 stepper motors
simultaneously.
Application:
Microscope scanning stages (Marzhauser, Prior, Olympus)
laser adjusting units
linear stage positioning, cross stage positioning.
Features:
· stepper controller 2 oder 3 axes
· Resolution up to 690.000 steps/rev.
· smallest step input: 1nm
· use of physical units
· velocity up to 60 rev. /s
· max. motor current 2.5A each phase
· programmable mode with host
· manual mode with Joystick
· ASCII command interpreter
· On Board macro commands
· Closed Loop interface RS422 or 1Vpp
· Digital Input/Output
· Position synchronous output (PSO)
· event controlled point of interest memory
· Analog output
· RS-232 Interface
· Ethernet Interface 10/100
· IEEE 488 Interface
· Position display
· 19 inch cabinet available
· Windows User Interface (WinPos)
|
|
saia stepper motor driver
Dimensions (mm) 55 x 40
Supply voltage (VDC) 10-24
Motor current constant voltage drive
Step mode full/half step
Clock source internal or external
Control inputs to inhibit internal clock, inhibit motor current, exchange direction
Configuration via DIP-switch
|
|
|
Step motor drivers are to control the step motors by the command of its upper class control equipment like PC, Controller, etc. Autonics 2 & 5 phase step motor of drivers of high resolution & quick response are definitely the optimized solutions for more efficient control of every step motor.
|
|
|
|
|
|
Power Stages
Tactful movement: power stages keep driving.
Power stages are used in the driver unit to produce a current signal out of a directional signal and a clock signal. This sets the stepper motor in the desired rotation.
SINCOS
Linear Stepper Motor Power Stage with Variable Current Profile
SINCOS is a linear stepper motor power stage particularly developed for applications which require high step resolution, such as: measuring tables, machine tools, graphic instruments, etc.
Technical Details
* Linear power stage for two-phase stepper motors, with 4,6 or 8 leads
* Maximum phase current: 2.5A (with cooling), 1.5A (without cooling)
* Drive and stop current continuously adjustable from 0 to 100%
* Selectable phase current profiles: sine-shaped, triangular or trapezoidal
* Supply voltage +20VDC and -20VDC
* Step resolution selectable from full step to 1 / 20 step
* Inputs TTL: Control pulses, Motor direction, Motor stop, Motor current OFF, Select, Reset
* Output open collector: Overtemperature
* Mounting in 19'' / 3 U sub-rack
|
|
The cost effective R208 provides customers with uncompromising performance without the usual high price that comes with such drivers.
Features:
• Bipolar step motor driver
• Potentiometer set phase current from
0.25 to 1.4 Amp RMS (2.0 Amp peak)
• Selectable step resolution from full step
to 8X microsteps
• Optically isolated step direction,
and disable/enable inputs
• Automatic current reduction with disable switch
• Low power dissipation
• Efficient current control
• Quiet operation
• Thermal shutdown, under-volt protection
• Power-on indicator
• Power disable/enable control
• Sinusoidal current wave form
Lin Engineering is now offering the High Powered R101 Driver.
Visit www.LinEngineering.com for more information.
|
|
GMH is the name of a series of ministep bipolar chopper drives, suitable for driving two-phase stepping motors, with four, six or eight terminals.
GMH drives are realized in single EUROPA format cards (100 x 160 mm.) and are equipped with a 32 pole, DIN 41612 form D connector. They are therefore designed to be assembled inside a RACK, complete with motherboard, that could be supplied as an option by R.T.A.
|
|
Step Motor Controler SM210A
* For stepping motors with 4, 6, 8 connections, max. 3A/phase
* Stored-program operation
* Synchronization to main drive
* Stand-alone operation or expansion unit for EFKA controls
* 8 digital inputs, 2 analog inputs, 5 outputs (60VDC, 0.5 A)
* Plug-and-play for 230VAC, 50/60Hz
* Integrated +24V power supply (100VA)
|
|
AMIS-30521/AMIS-30522: Stepper Motor Driver
This is a micro-stepping stepper motor driver for bipolar stepper motors; the IC can be interfaced via I/O pins and the SPI bus to an external microcontroller.
AMIS-30621/AMIS-30622: Stepper Motor Driver and Controller with LIN Bus and Micro-stepping Features
This 800mA bipolar 2-Phase stepper motor driver with position controller and LIN bus interface acts as a mechatronics driver remote from a microcontroller.
AMIS-30623/AMIS-30624: Stepper Motor Driver and Controller with LIN Bus, Micro-stepping Features, and Stall Detection
This 800mA bipolar 2-Phase stepper motor driver with position controller and LIN bus interface acts as a mechatronics driver remote from a microcontroller.
|
|
Modules Stepper
If you are looking for the flexibility of designing in our motion ICs but lack the time, resources or volume, consider using the module solutions or PANdrives.
These modules are complete embedded motion control solutions and retain the potential for customization. They are ready to use and can be easily integrated into the users' application at an unbeatable price/performance ratio.
|
|
Features
The UI2120G Intelligent Stepping Motor Driver combines a high performance stepping motor driver with microprocessor intelligence and an integrated pulse generator. Motion control features include built-in digital switches to control the amount of travel, initial speed, running speed, acceleration and deceleration.
Minimal Wiring
A driver with an incorporated pulse generator offers simple wiring and easy setup.
Easy Operation
The UI2120G includes all functions necessary for controlling a 2-phase stepping motor. Motion control settings include: start, stop, rotation direction, travel amount, speed, acceleration, deceleration, step angle, and return to mechanical home. Data can be easily set by switches on the front control panel.
|
|
|
|
|
|
R325 - Microstepping Driver with Pole Damping Technology
Operates from 15 to 48 VDC
Phase current from 0.3 to 3.0 Amps Peak
Step Resolutions from Full to 256 microstepping
Hold current reduction capability with adjustable current and timeout settings
Three optically isolated control inputs and one optically isolated control output
Pole Damping™ Technology
R325I & R325IE additional features
Configuration parameters stored in non-volatile memory
Multiple module control through software assigned single character addresses
Built-in control routines for trapezoidal position and velocity moves
What is Pole Damping™ Technology?
Pole Damping™ Technology (PDT) enhances step motor performance by dampening each full step in order to create a more accurate and smooth motion profile. Microstepping the step motor will optimize Pole Damping™ Technology. PDT outputs the correct amount of run and hold currents to the motor. Thus, it will overcome the step motor’s natural tendency to want to forcefully pull towards the full step ON position.
Currently, the Silverpak 23D integrated motor + drive and the R325 Microstepping Driver contain Pole Damping Technology.
|
|
Smart drives and indexers
PCB
credit card size
hi-res micro-stepping
closed loop ServoStep
40VDC/3Аmp
Smart drives and indexers
panel mount
hi-res micro-stepping
closed loop ServoStep
80VDC/6Аmp
Programmable standalone
Networked indexers
RS-232 network
stand-alone indexer
hi-res micro-stepping
PLC interface
110/220AC
Brushless servo amplifiers
Networked indexers
CAN network
stand-alone indexer
closed loop servo controls
sinusoidal commutation
PLC interface
110/220AC
Multi-axes motion controllers
multi-axes controller (1-8)
closed loop servo controls
micro-stepping controls
Ethernet network
PCI, ISA, VME, PC104
|
|
2-phase Stepping Motor Driver(KS9110)
This high torque, 2-phase step motor, in both 17 and 23 style, in conjunction with a small size, low price unipolar constant current chopper driver (KS 9110), meets all the need of the OA and FA industry.
Usage
XY tables, XY plotters, electrical cylinders, printers, press rollers, FAX machines, physics & chemistry equipment, medical equipment, valve controls, semiconductor conveyors, etc.
|
|
Application : Apply to all kind of stepper motor (Internal power can auto Tuning to stepper motor).
Feature:
- Supply Voltage range DC12V ~ 40V,Output Current maximum up to 3A.
- The driver provide complete control and pulse-width modulation (PWM) control of the output current Full- ,Half-, quarter-, and eighth-step operation selectable.
- Selectable current make stepper motor performance in high efficiency without rising temperature.
- The driver can hold motor in any 1/8 micro step position while motor stop...
- Torque setting in 100% or 141% in full step.
- Control mode 1P/ 2P selectable.
- Input frequency maximum Uni-polar up to 200K ,Bi-polar up to 500K. Apply to all kind of mechanical movement with pulse generator.
- The driver include multi PWM channel core ,and low power dissipation.
- Input method in Photo-Coupler designed, interruption free and indicator for CW / CCW. Easy to operate, inspect and maintain.
|
|
1-channel microstep board 'HP-Step'
Features:
* 1 stepper motor channel
* Connect up to 6 boards (4 axes) to PC printer port (with optional interface board or adaptor cable)
* Easy adjustable motor current 1A up to 4A each phase (via trimmer)
* 15-45 Volt motor power supply
* single supply operation
* TTL-compatible in- and outputs (5Volt)
* connectable to PC-printerport or Microcontroller
* compatible to common CNC software (PCNC, CNC-profi, DIN-CNC, Mach2, EMC etc.)
* 1/10-, 1/5-, 2/5-, 1/8-, 1/4-, half- and fullstep
* fast 10bit DAC for generation of micro steps
* "Softstart-Function" saves power bridges and power supply
* improved short circuit protection
* DIN 41612 Typ D connector for 19" rack systems
* Size: euro size 160x100mm
|
|
1-channel microstep board 'HP-Step'
Features:
* 1 stepper motor channel
* Connect up to 4 boards connect to PC printer port (with optional interface board or adaptor cable)
* Easy adjustable motor current 1A up to 4A each phase (via trimmer)
* 15-45 Volt motor power supply
* TTL-compatible in- and outputs (5Volt)
* connectable to PC-printerport or Microcontroller
* compatible to common CNC software (PCNC, CNC-profi, DIN-CNC, Mach2, EMC etc.)
* 1/8-, 1/4-, half- and fullstep
* max. input frequency 30 kHz, dynamic reduction of step width (at 8.5 and 19 kHz)
* Adjustable chopper frequency
* "Softstart-Function" saves power bridges and power supply
* Typical current consumption 75mA (5V part)
* Suitable for both bi- and unipolar stepper motors with minimum 0,8 ohms coil resistance
* outputs short protected (self resetting)
* Size: 100x100mm
|
|
1-channel microstep board 'Tiny-Step'
Features:
* 1 stepper motor channel
* Connect up to 4 boards connect to PC printer port (with optional interface board or adaptor cable)
* Motor current up to 2,25A (peak) or 1,6A (eff.) each phase, easy adjustable via trimmer
* 15-35 Volt motor power supply
* TTL-compatible in- and outputs (5Volt)
* connectable to PC-printerport or Microcontroller
* compatible to common CNC software (PCNC, CNC-profi, DIN-CNC, Mach2, EMC etc.)
* 1/8-, 1/4-, half- and fullstep
* Typical current consumption only 15mA (5V part)
* Suitable for both bi- and unipolar stepper motors with minimum 1,6 ohms coil resistance
* Size: 60x100mm
|
|
mechapro introduces the HEM-545 2-phase stepper motor driver with significant reduced driver losses. The standard version accepts clock and direction signals. An optional version can also process an analogue speed signal (+/-10V). The driver has a supply range of 15 to 45V= and can be set to motor currents between 2A and 5A. Step modes from full step to 1/16th micro step can be used.
Compared to the previous product the power consumption of motor and driver was reduced up to 35%. Therefore the driver needs no extra heatsink or fan. The board is delivered as a closed unit including an aluminium cover; the size is only 146*77*25mm. Although it is completely made in Germany, the price is competitive to products from Far East. The first units will be available at the end of September.
|
|
The MForce MicroDrive Motion Control is a 2.0A RMS microstepping drive integrated with a full-featured programmable motion controller.
Controller features include:
* Robust programmable I/O (up to 12 general purpose points) with input filtering
* Powerful instruction set with advanced math functions using 1-2 character mnemonics
* Step/Direction I/O for electronic gearing
* RS-422/485 or CANopen communications
|
|
The MForce PowerDrive Microstepping is an advanced, high resolution microstepping driver with an output current of 5 A RMS (7 A Peak). Features include:
* Advanced current control for unsurpassed smoothness and performance
* 20 microstep resolutions from full step to 51,200 steps per revolution
* Optically isolated logic can accept sinking or sourcing inputs ranging from +5 to +24 VDC
* All parameters are software configurable (setup utility included) - no external switches or resistors require
|
|
The SMD41/42 series of micro and mini-step drivers is available in 13 different models, with supply voltages from 15VDC to 160VDC, 3, 6 and 9 Amp models, full- half-, mini- and micro-step resolutions that can be changed by dipswitch, up to 25000 step/revolution, and more.
The 160V driver, SMD42 is physically similar to the popular SMD41 mini-step driver, but is intended for high-velocity, high-torque applications. The SMD42 can be powered by a 160VDC supply (compared to 80VDC for the SMD41). This yields up to double the torque at velocities over 500RPM. Heat generation is kept to an absolute minimum through the use of the latest MOSFET technology.
Together with JVL step motor MST 340-342, the 160 V version, SMD42, achieves a remarkable torque of 7-8Nm even at high velocities.
|
|
|
|
|
|
Bipolar Type Micro-Step Drive
FAS-2SD-MB450
Bipolar 2 Phase Micro-Step Drive, 5000 pulse/rev., 4A/Phase
The most suitable to control the semiconductor & LCD manufacture equipments, robots, inspection equipments, dispecser, cutting machine & processing facilities.
FAS-2SD-MB420
Bipolar 2 Phase Micro-Step Drive, 2000 pulse/rev., 1~4A/Phase
The most suitable to control the semiconductor & LCD manufacture equipments, robots, inspection equipments, dispecser, cutting machine & processing facilities.
Unipolar Type Micro-Step Drive
FAS-2SD-MU450
Unipolar 2 Phase Micro-Step Drive, 5000 pulse/rev., 4A/Phase
The most suitable to control the semiconductor & LCD manufacture equipments, robots, inspection equipments, dispecser, cutting machine & processing facilities.
FAS-2SD-MU316
Unipolar 2 Phase Micro-Step Drive, 1600 pulse/rev., 3A/Phase
The most suitable to control the semiconductor & LCD manufacture equipments, robots, inspection equipments, dispecser, cutting machine & processing facilities.
FAS-2SD-MU350
Unipolar 2 Phase Micro-Step Drive, 50000 pulse/rev., 3A/Phase
The most suitable to control the precision stage, semiconductor & LCD manufacture equipments, robots, inspection equipments, dispenser, cutting machine & processing facilities.
FAS-2SD-MU3200
Unipolar 2 Phase Micro-Step Drive, 200000 pulse/rev., 3A/Phase
The most suitable to control the ultra precision stage, semiconductor & LCD manufacture equipments, robots, inspection equipments, dispenser, cutting machine & processing facilities.
|
|
KR-55ME-SS
Five-phase micro-step driver
Features
Micro-step driver for five-phase stepping motors with a 24V DC power supply input
16 step angle types can be set with up to 250 divisions and 125,000 pulses per revolution.
A low-vibration function ensures reduced vibration for full-step drive.
Two types of micro-step angle can be selected as required using a selector signal.
|
|
MCR-MUP2403B Micro-Stepping Motor Driver
Features:
Supply Voltage range DC12V ~ 40V, Output Current maximum up to 3A.
- The driver provide complete control and pulse-width modulation (PWM) control of the output current Half-, quarter-, eighth-, and sixteenth-step operation are externally selectable .
- Selectable current make stepper motor performance in high efficiency without rising temperature.
- MUP2403S can hold motor in any 1/16 micro step position while motor stop..
- When motor stop , MUP2403S holding current can adjustable.
- Control mode 1P/ 2P selectable.
- Input frequency maximum up to 220KHz.
- The MUP2403 include multi PWM channel core ,and low power dissipation.
- Input method in Photo-Coupler designed¡Ainterruption free and indicator for CW / CCW. Easy to operate, inspect and maintain.
|
|
Sanyo Denki offers a complete range of stepping systems with 2PH, 3PH and 5PH stepping drivers and motors, and specific technologies such as PB closed loop models, all-in-on stepper units, RS-485 interface stepping drivers and a complete lineup of stepping motors with encoders.
28 mm square size up to 106 mm round stepping motors are available.
|
|
Haydon can supply high performance drivers for its entire range of stepper motors and linear actuators.
From simple L/R constant voltage drives to sophisticated chopper drives with micro stepping capabilities, Haydon’s drives simplify product development and power-up any application.
Competitively priced, our new DCM8028 and DCM8055 micro stepping drives are particularly useful in motor applications requiring low noise, low vibration, high speed. They are also suitable for large volume OEM applications up to 70 VDC and 5.5 Amp per phase.
HAYDON drivers can be used in various kinds of machines, such as X-Y tables, labeling machines, laser cutters, engraving machines, and pick-place devices.
|
|
|
|
