Pimento can handle most tasks in general data acquisition & DSP, rotating machinery, structural analysis and acoustics, including sound power and sound intensity measurements. It comes in a highly portable unit that responds to your needs just as conveniently at home, in the lab or in the field.
|
|
- The main use of the instrument is in lubrication replenishment process.
- The instrument measures the actual lubrication level of a bearing and tells the operator when the amount of added lubricant is ideal.
- It ensures that bearings are not under or over lubricated.
- Use of this instrument decrease lubricant consumption and machine maintenance cost.
- It also display the bearing condition value.
- Built-in Stethoscope.
- Simple operation.
|
|
OROS offers breakthrough noise and vibration analyzers, the OROS 3-Series.
From 2 to 32 channels these comprehensive instruments offer powerful real-time analyses associated with a disk data recorder packaged in portable and professional units.
The OROS 3-series analyzers are flexible enough to handle your measurement, whatever the application. These instruments overcome most of the measurement obstacles with their wide frequency span from milliHertz to 40 kHz and the extensive 140 dB dynamic range. Thanks to these attributes, OROS 3-Series analyzers are the right choice for all your NVH activities.
4 mobile, real-time, multi-channels analyzers in the OROS 3-Series range: OR34, OR35, OR36, OR38.
|
|
FastTracer
• Vibration triaxial analyzer
By positioning the FastTracer directly on the test point it is possible to acquire immediately the required information on the three axes allowing the operator to save time.
•USB portable
Plug and Play device with USB connection or wireless. Thanks to MEMS technology the sensor is highly miniaturized and it can be mounted on the most critical test points.
•Powerful and cheap
The acquired acceleration data are sent to the PC that then performs the data processing through the supplied software.This solution allows the full exploitation of the computation capacity of the PC by obtaining some advantages as fare as velocity,precision and costs of the product are concerned
•Real-time analysis in time and in frequency
The included software allows the operator to do real-time analysis both in time and frequency domain (acceleration, velocity, displacement, RMS). The user-friendly interface permits the analysis viewing in the most proper and flexible way
•Off-line and remote analysis
The data acquisition can be recorded in the PC and then investigated with the same interactivity of an online viewing or it can be easily transmitted via internet both in real time or through automatic reports in Microsoft EXCEL
•Accuracy and precision of measurements
An internal autodiagnosis system always ensures the correct working of the instrument by guaranteeing at the same time the precision of the effected measurements
•High flexibility with other software
The high adaptability of FastTracer in different fields has permitted a high grade of integration with the most common control systems (LabView, CVI, etc)
|
|
The OROS 3-series analyzers are flexible enough to handle your measurement, whatever the application. These instruments overcome most of the measurement obstacles with their wide frequency span from milliHertz to 40 kHz and the extensive 140 dB dynamic range. Thanks to these attributes, OROS 3-Series analyzers are the right choice for all your NVH activities.
Able to accurately manage all types of Tach /keyphasor, OROS 3-series analyzes rotating machinery signals with their comprehensive toolset. Synchronous order analysis and constant band order tracking reveal hidden details during speed variation. The 3D waterfall and profiles give clear overviews of coast-downs or runs-up.
Acquire, Store, Analyze and Report is your everyday work in noise and vibration tests and R&D? Automotive, Aerospace, Consumer, Industry and Energy are demanding domains where you get more and more data to measure while delays for the results delivery are getting shorter. Focusing on your time to result challenge, OROS offers breakthrough noise and vibration analyzers, the OROS 3-Series. From 2 to 32 channels these comprehensive instruments offer powerful real-time analyses associated with a disk data recorder packaged in portable and professional units.
|
|
LMS Test.Lab 24 Channel MIMO Modal Analysis
System for multi-shaker or hammer excitation -
The entry-level LMS Test.Lab MIMO system provides a complete modal testing solution supporting single or dual shaker and impact hammer Frequency Response Function Measurements for up to 24 simultaneous channels, all supporting ICP® transducers or any Voltage signal.
|
|
The OROS 3-series analyzers are flexible enough to handle your measurement, whatever the application. These instruments overcome most of the measurement obstacles with their wide frequency span from milliHertz to 40 kHz and the extensive 140 dB dynamic range. Thanks to these attributes, OROS 3-Series analyzers are the right choice for all your NVH activities.
Whatever the method you are using, Impact hammer or SiMo/MiMo shaker excitations, FRFs are acquired confidently. A set of innovative tools such as node path sequencer and preview of averaged coherence dramatically speeds up modal data acquisition.
Acquire, Store, Analyze and Report is your everyday work in noise and vibration tests and R&D? Automotive, Aerospace, Consumer, Industry and Energy are demanding domains where you get more and more data to measure while delays for the results delivery are getting shorter. Focusing on your time to result challenge, OROS offers breakthrough noise and vibration analyzers, the OROS 3-Series. From 2 to 32 channels these comprehensive instruments offer powerful real-time analyses associated with a disk data recorder packaged in portable and professional units.
|
|
The Ultraprobe 10,000 brings Ultrasound Inspection technology to a whole new level. With this one system, inspectors can perform condition analysis, record sounds, store and manage data.
With the push of a button, it is now possible to record a sound sample directly into the instrument and link it to one of 400 record files stored in the Ultraprobe.
Specialized Application Screens
Adjustable On/Off Features
Connect to External Devices
Flexible Reporting Options
|
|
Vibration Supervisor DMM-4000/TGV
These field mounting devices consisting of sensor and specific transmitter prepared for preventive control of vibration in bearings of heavy machinery by means a trending system activing alarms according several criterium. These models transmit RS-485 Modbus and 4-20 mA signal proportional to the vibration speed. Optionally can transmit by Radio, Ethernet cable or WiFi.
|
|
|
SignalStar Matrix Vibration Controller unites the all new ABACUS DSPcentric hardware platform with the highly acclaimed Data Physics vibration control software to produce a complete and fully integrated solution redefining the boundaries of vibration testing. The greatly intuitive User Inter-face makes it easy to setup and run the most sophisticated vibration tests to the top specifications in the Industry. Matrix provides time and frequency domain displays of drive, control and measurement signals to give the operator immediate feedback on control quality. For example, harmonic distortion in Sine or sigma clipping in Random can be measured and displayed. A unique feasibility check is provided by the pre-test mode which does a loop check, assesses the integrity of all system inputs, measures the system transfer function matrix and verifies that the test may be run safely on the selected shaker system. The User Interface language can be chosen from a list allowing an operator in France, Germany or Japan to operate the system as easily as an operator whose native language is English. A well-presented test report says a great deal about the quality of the test. SignalStar Matrix desktop publishing module allows users to design professional quality reports, which can be automatically created during operation. All equipment in your lab only need to be logged once in the system which can then be quickly recalled when creating tests. Learn more about all of of SignalStar Matrix's features
|
|
|
SignalStar Scalar does not require a host computer. It is made easy to use by leaving out parameters that are rarely required. It gives you the best of both worlds. No other vibration controller compares with the combination of simplicity and powerful control in a package that costs so little. SignalStar Scalar is the ideal vibration controller for users looking for a powerful system yet are on a tight budget. SignalStar Scalar derives its capability from the acknowledged leader of vibration control, SignalStar Vector, incorporating the same powerful ABACUS digital signal processing hardware and control algorithms. Scalar is offered in a basic configuration with only the most commonly needed features. Unlike most entry level controllers, Scalar can be configured with optional features that are usually offered only on the most advanced vibration controllers, making it easy to configure just the right system for your test and your budget. The ability to add software options in the future also protects your investment in Scalar as your testing needs grow.
|
|
Advanced solution for noise & vibration analysis
very analyzer makes promises. Smaller, faster, more powerful, more portable, more connected, less trouble, more intuitive …. The proof is in going out and making the measurements, out in the world where cables are tangled and signals are noisy, where you're not sure what you're looking for but you have to get the data anyway because there's only one chance. The proof is in making realtime measurements while recording raw data to disk. No more guesswork, no blind recording. The proof is in countless re-analysis back at your desk.
Comprehensive Measurements
The modular software allows you to select only those measurements you need from an extensive range covering general FFT analysis, data recording and playback analysis, environment testing, structural analysis, acoustics, machinery diagnostics and production/QC testing.
Modern Architecture - Distributed DSP Power
SignalCalc Mobilyzer that runs on ABACUS dynamic signal analysis hardware, a compact network peripheral that brings the power of distributed DSP architecture to the field and laboratory. ABACUS distributes the processing load to achieve high speed, high quality signal analysis, and interfaces to a notebook or desktop computer via a standard Ethernet connection. The ABACUS chassis contains a Pentium CPU controlling multiple data acquisition and signal processing modules. The architecture is optimized for efficiency by dedicating a high speed DSP to each group of channels. This ensures that processing speed is maintained at the same high rate regardless of the number of channels in use.
|
|
Type 107B - A, V, S vibration meter, spectrum analyzer
800 lines FFT, logarithmic/linear view.
Charge amplifier with programmable sensitivity
(use any piezoelectric accelerometer with known sensitivity).
Frequency range 2...10000Hz.
Firmware update by user. Free Windows software ConSpect.
USB interface ("Mass storage device"). FAT16 file system. 2MB memory.
NiMH accumulator, charger. Aluminum casing.
Size- 110x60x30mm.
|
|
|
The 795M is an economical portable single channel multi-function data collector and 1600 lines FFT spectrum analyzer. It is versatile for overall values measurement, bearing condition diagnostic, spectrum diagnosis and in-situ multi-plane balancing of rotating machinery (up to 8 planes of correction, up to 16 point to check vibration). It is a simple and useful device that allows for easy condition monitoring and unbalance correction of any rotating equipment found almost in every process industries. With the Windows based “ConSpect” software, it creates an easy to use, cost effective, scalable solution that meets the needs of the novice as well as advanced user. The small, rugged, and light weight IP65 design makes it ideal for any harsh industrial environments.
|
|
USB BALANCER
The solution for the detection and the correction of the unbalancing of rotatory elements. Directly linked to the USB port of the PC the USB Balancer allows in a few minutes the automatic identification of the rotary speed, the determination of unbalancing quantity and the instructions for the correct balancing. The absence of photocells and of any additional electronics guarantees the extreme handling of the product at very low costs. Furthermore, the USB Balancer allows:
- no need to do a periodical calibration
- quick installation
- triaxial acceleration reading with selection of unbalancing plane
- automatic reports at the end of measurements
|
|
The most complete and reliable solution for the full spectrum of tightness testing, leak detection and predictive maintenance.
The SDT 170 encompasses our company's vast experience in the fields of ultrasonic leak detection, tightness testing and predictive maintenance. It is robust, lightweight, user friendly and ergonomically designed. It provides a totally efficient, and simple response to proper and effective equipment maintenance and product quality.
|
|
P.I.N.D. - Particle Impact Noise Detection
Vibration Shock and Acoustics to insure the highest of reliability
For over thirty years the PIND Products Group of SPECTRAL DYNAMICS, INC. has given users a simple, reliable, and inexpensive method of Particle Impact Noise Detection (PIND) testing to increase the reliability of electronic components.
Our non-destructive high frequency acoustic test monitors for loose particles moving inside high reliability internal cavity electronic components such as relays, transistors, hybrids, integrated circuits, and switches – particles that have the potential of causing short circuits and serious malfunctions in system operations.
|
|
Portable Vibration Analysis & Monitoring System
Vibration Analysis and monitoring has never been easier than with IOtech's Zonicbook/618E and eZ-Series analysis and monitoring software. This Eternet-based solution adds another dimension; the lowest cost full-featured 8-56 channel analyzer available.
Key Highlights
* 8 dynamic input channels, expandable up to 56 channels
* 4 tachometer channels for rotational measurements
* High-speed Ethernet connection to the PC for continuous recording
* Four e-Z-Series software packages address a wide variety of vibration monitoring and analysis applications
* TEDS support for accelerometers
|
|
COUGAR Portable Dynamic Signal Analyzer
* 4 to 28 input channels with ICP
* Up to 51.2 kHz sample rate per channel
* Powerful distributed Digital Signal Processors
|
|
PUMA / COUGAR Vibration Control and Analysis System
Puma Revolutionizing Vibration Testing
PUMA (Cougar for portability) utilizes Spectral Dynamics’ innovative Computer-Aided Test Suite™ (CATS) architecture. Both take full advantage of the PC’s powerful Intel processor and Windows XP technology. Optimized for multi-tasking, and founded on industry connectivity and data interchange protocols, the CATS make your entire test and validation process more timely and efficient.
Versatile Test Capabilities
The Computer-Aided Test Suite™ vibration control and analysis applications were designed to meet a wide range of test requirements. With scalable hardware and software the Vibration Control and Analysis System combines the simplicity of operation required for production screening with the power and versatility required for R&D prototype testing.
Technical Specifications
• 4 to 32 input channels with ICP
• Analysis to 40 kHz with 12,800 lines
• Scalable h/w and s/w architecture
• Powerful Multiple DSP architecture
• Comprehensive vibration test capabilities
• Extensive laboratory integration and test automation features
|
|
The most cost-effective, accurate, powerful entry into Structural Analysis available today.
Bobcat, built for:
Vibration Analysis
Transient Analysis
Acoustical Analysis
Modal Analysis with enhanced features
Swept Sine Analysis, with Tracking Filters
Signal Analysis with optimal displays
Simply making accurate measurements
|
|
The WCA mini AD3661 - It goes where you go- Portable 4-channel Noise & Vibration Analysis System
- USB bus power unit
- 24 bit, 4-channel measurements
- A channel exclusively for tacho pulse measurements
- WCAPRO (multi analysis software)
- FFT analysis and real-time octave analysis
- Tracking analysis and throughput recording/playback
- Equipped with WCA Lite (easy-to-use analysis software)
* Configuration
Standard configuration
- AD3661 Hardware (size: 30(H) x 139 (W) x 138(D) mm, weight: 330g,
including UBS cable and power adaptor)
- WCA Pro software and license for basic FFT analysis
* Options for WCA Pro software
2D tracking license
3D tracking license
Real-time Octave analysis license
Time-series filtering license
[Features]
A portable and lightweight, USB bus powered unit
The WCA mini is small and light enough to fit into your travel case. Its actual size is Height 30mm (height) x Width 139mm x Depth138 mm (width), and weights is only 330g. Power can be supplied from athe USB bus, allowing you to perform noise and vibration analyses anywhere.
User-friendly GUI and WCA Lite with improved ease of operation
With enhanced operability, the WCA mini has adopted the same design concept employed in the highly reputed WCA. WCA Lite will enable simple operation of FFT and tracking analyses.
Complete compatibility with the CompactWCA/WCAonPC
A compatible user interface eliminates the need for additional training of existing users.
WCAPRO, multi-analysis software
WCAPRO provides real-time FFT analysis for noise & vibration testing.
Please see the AD-3661 catalog for further details.
|
|
|
LMS provides a vehicle-based acquisition system for noise emission evaluation of vehicles against predefined targets, legislative standards like the ISO 362, SAE J1470 and upcoming standards with a strong focus on enabeling high channel counts for parallel engineering analysis measurements. Addionally, the acquisition and analysis tools for in-depth engineering analysis of noise emissions enable the user to design for noise emission levels lower then ever and achieving attractive brand sound characteristics
|
|
NetdB: Control of noise and vibration sources
With V1.5, the latest version of its firmware, NetdB allows for the generation of an infinite range of signals on its analogue and digital output channels.
Well beyond the standard capacities of equivalent acquisition front ends available on the market (fixed-frequency sine, swept sine, burst, white/pink noise), it can also be used to generate MLS sequences, to apply real-time filters on inputs and redirect them to output channels and to generate any type of signal from a wav file.
NetdB makes it very easy for you to control a vibration excitation bench, a loudspeaker, headphones for Jury listening, etc., i.e., any excitation or signal restoration system regardless of your application field.
|
|
Two-channel Analyser, Collector, Balancer, Recorder
OneProd MVP-2C is an “all-in-one” modular system designed to improve the reliability of your machines through vibration analysis.
OneProd MVP-2C is equipped with a high-brightness colour screen and its user-friendliness favours users’ comfort and productivity.
Ultra compact, 2 x 40 kHz channels + trigger input channel, for the control and analysis of vibrations in industrial settings:
• FFT analyser,
• Data collector,
• Balancer,
• DAT recorder,
• Order analyser,
• Pyrometer (°C),
• Integrated laser-sighting tachometer (RPM).
Full set of tools for the detection and analysis of bearing defects (Bearing factor, Kurtosis, Envelope) – Automatic contactless identification of the measurement point – Communication through USB, RS232 and Internet (e-Route module). Exists in intrinsically-safe mode for measurements in areas where explosion hazard is permanent (zone 0).
|
|
|
The international community has recently drawn considerable attention to occupational vibration and it's detrimental effects on the human body. In response to these new developments, Quest has released the HAVPro personal human vibration monitor and the "New" VI-400Pro real time vibration analyzer.
|
|
Description :
The Virtual Corset™ has been described as "a gentle reminder to stand up straight". A more erect posture can reduce trunk muscle activity, and may reduce the loads borne by the spinal column.
By combining an inclinometer, data logger and silent vibrating alarm in a tiny pager enclosure, the Virtual Corset™ keeps track of trunk inclination, and warns the wearer when a prescribed inclination angle limit has been reached. The clinician or therapist sets the unit's inclination limits, sample frequencies, and data save intervals using the serial port of a personal computer (PC); once programmed, the Virtual Corset may be disconnected from the PC. In the field, it performs its pre-programmed datalogging and biofeedback tasks while worn anywhere: during work, play, exercise, and rest.
|
|
CATS Modal
CATS Modal integrates all the functionality of STAR Modal into our Computer-Aided-Test-Suite of applications, combining acquisition with analysis for unparalled power and efficiency.
Data Acquisition
Integrated data acquisition makes acquiring and managing large sets of modal data easier than ever. Automated management of measurement DOF simplifies data acquisition for multiple data sets and reduces test time. A built-in signal generator provides user-specified excitation type (random, sine, chirp, burst random, user-defined) and amplitude control.Upgrading to Premier Modal Data Acquisition adds the ability to acquire multiple-input, multiple-output (MIMO) modal data.
For acquisition of long time history events, the optional removable SCSI throughput disk provides simultaneous acquisition of time data to disk for up to 128 input channels at up to 51.2 kHz sample rate per channel.
|
|
WaveBook/516E
Ethernet-Based Portable High-Speed Waveform Acquisition
WaveBook/516E digitizer offers multi-channel waveform acquisition and analysis for portable or laboratory applications; includes 8 built-in channels expandable up to 72 channels of voltage, accelerometer, microphone, strain gage, thermocouple, position encoder, frequency, high voltage, and other signal types.
Key Highlights
• 16-bit/1-MHz A/D
• 1 µs/channel scanning of any combination of channels
• Single and multichannel analog triggering with programmable level and slope
• Digital TTL-level and pattern triggering
• Pulse trigger and external clock
• Programmable pre- and post-trigger sampling rates
• Sixteen digital inputs can be scanned synchronously with analog signals
• Operable from AC line, a 10 to 30 VDC source, such as a car battery, or optional compact rechargeable battery module
• Expandable up to 288 high-speed channels
• SYNC connection allows multiple units to sample synchronously
• Add up to 854 lower-speed thermocouple channels
• DSP-based design provides real-time digital calibration on all channels
|
|
