Mounting - Snap-in Mount Module
Dimensions (mm) - 25 x 25 x 7.7
Operating temperature - -40 °C to +85 °C
Standards - GPS/QZSS/Galileo
Frequency - 1575.42
Passive Gain (dBi) - ~3.6
Impedance (Ohm) - 50
Voltage Range (V) - 3.0 - 5.0
Active Gain (dB) - 25 @ 5.0 V
Noise Figure (dB) - 2.5 @ 5.0 V
Current Consumption (mA) - 20 @ 5.0 V
Power Consumption (mW) - 100 @ 5.0 V
Saw Filter Type - Pre-Filter
Out of Band Rejection (dB) - 43
ESD Protection (kV) - 2
