Automotive part presses

Force: 9,806.7 kN
Opening: 1,100 mm

Product characteristics： Frame structure: welded frame structure made of high quality steel plate and annealing process, confirm the elastic deformation in maximum pressure through finite element analysis, guiding of moving bolster ...

Force: 100 tf - 2,000 tf
Opening: 800 mm - 2,000 mm
Stroke: 500, 800, 1,200, 1,500 mm

Ease operation: user friendly HMI, ease for setting parameters and recipe storage; Control system: PLC + HMI (Siemens brand), refer to pressing technology requirement set the parameters on HMI such as pressure, position, hold pressure, ...

Force: 300 tf - 1,500 tf
Opening: 1,000, 1,200, 1,100 mm
Stroke: 500, 450 mm

Servo Frame Type Die Spotting Press Product characteristics： Frame structure: welded frame structure made of high quality steel plate and annealing process, confirm the elastic deformation in maximum pressure through ...

Force: 0.5 kN - 120 kN
Opening: 66 mm - 220 mm

Unit Type Servo Press -Electrically-powered JP Series 5 runs cleaner and quieter than pneumatic and hydraulic presses, with lower power consumption. -Interactive, user-friendly programming, and multiple pressing ...

Force: 1,000, 2,000, 3,000 kN

Kurtz KPS SKT Trimming Presses with sliding-tilting table function - Sliding function via hydraulic cylinder - Hydraulic swivel drive tilts up to 180° - Tilt angle freely programmable - Speed profile free programmable - Recipe ...

Force: 500, 1,000, 2,000, 3,000 kN

KPS - Column Version - Ideal solution for tall parts and parts with large volume - Loading and removal possibilities from four sides - Robust, strongly dimensioned guiding columns - All possibilites ...

Force: 32, 52, 67, 100 tf

Trimming Presses in C-Frame Design Free access from all sides Simple robot handling Full use of the whole table and clamping platen area The size of the trimming tool is not limited by the table and clamping platen area Ideal ...

Force: 880 kN
Opening: 196 mm
Max. pressure: 250 bar

... and innovative solutions for revolution parts with only one vertical punch, a very high speed, and the option to produce up to 3 parts per stroke. V1.32 is the more specific model for a determined type ...

Force: 980 kN
Opening: 200 mm
Max. pressure: 250 bar

PRESS PUNCHES - 3 horizontal PRODUCTION (empty) - From 500 to 3.600 parts/hour BAR DIAMETER - From 12 to 32 mm (From 0.47 to 1,26 in) BAR LENGTH - To 4.000 mm (To 2.65 lb) DIE DIMENSONS 205 x 205 mm This ...

Force: 980 kN
Opening: 500 mm
Max. pressure: 250 bar

... slightlest parts with the use of more cilynders to decrease the weight. Moreover, Neotecman’s design is based in a double structure for press and furnace, that includes the assembly of a robot to offer ...

Force: 10 kN - 2,941.8 kN
Opening: 0 mm - 1,000 mm

Our polymer hot press consists of a hydraulic press with automatically operated and two heated platens. The temperatures of heated platens are controlled by PLC. Water cooling jackets are installed at ...

Force: 0 kN - 2,000 kN
Opening: 200 mm - 1,900 mm

... Outstanding Precision • - Good Ergonomics • - Parallelism Measuring Function Why Die Spotting Press • - It allows you to conveniently match all the parts of the mould in more comfortable position. Check ...

Force: 0 N - 1,200 N
Opening: 170 mm - 1,470 mm

Die Spotting press is the most sure & safe way to check the butting of core & cavity of Die & Mould. It allows you to conveniently match all the parts of the mould in more comfortable position. Check ...

Force: 0 kN - 3,200 kN
Opening: 130 mm - 2,230 mm

... main components for mechanical processing are manufactured by imported machining center, to ensure machining precision of press elements. The shift-out rail of lower mold plate adopts wear resistant rail with intensified ...

Force: 100 kN
Opening: 50 mm - 1,000 mm
Stroke: 1 mm - 20 mm

Force: 180 kN
Table width: 770 mm
Table length: 660 mm

... Hydraulic cylinders drive the lower extensible plate outside the columns in an easily accessible position for the work outside the press. It slides on roller bearings and is laterally guided by ball bearings, completely ...

Force: 300 kN
Table width: 980 mm
Table length: 750 mm

... spotting presses. The control panel of the BV 26 C is equipped with user-friendly graphics to simplify the use of the spotting press. Platen dimensions are 980×750 mm (38X29 inches). The max. clamping force is 300kN. The ...

Force: 300 kN
Table width: 980 mm
Table length: 750 mm

... Hydraulic cylinders drive the lower extensible plate outside the columns in an easily accessible position for the work outside the press. It slides on roller bearings and is laterally guided by ball bearings, completely ...
