Vessel sight glass Type 327

sanitaryfor the pharmaceutical industryfor hygienic applications

The threaded sight glass Type 327 is a hygienic, threaded tank sight glass based on DIN 11851 / EN 10357 designed for areas with high hygiene requirements (food, pharmaceutical, medical). It is suitable for liquid and gaseous media and can be configured with accessories to meet specific process needs.

Standards & basic construction

• Manufactured in accordance with DIN 11851 / EN 10357 (threaded socket welded to an open pipe socket).
• Media-contacting side sealed with a borosilicate glass disc per DIN 7080.
• Sealing via a specially shaped O-ring; components secured by a slotted nut for reliable seating.

Available nominal sizes (DN)

• 25
• 32
• 40
• 50
• 65
• 80
• 100
• 125
• 150

Nominal pressure (PN)

• PN 6
• PN 10 (typical working pressure up to 10 barg)

Temperature ratings

• 80 °C
• 130 °C
• 150 °C
• 180 °C
• 200 °C (heat resistant up to 200 °C depending on configuration)

Options

• Wiper SGW with PTFE or silicone blade
• LED illumination for non-Ex areas
• FEP or Halar® coating for increased chemical resistance

Dimensions (summary by DN)

• DN 25 — D1: 26 mm; D2: 29 mm; D3: 63 mm; L: 37 mm; Weight: 0.31 kg
• DN 32 — D1: 32 mm; D2: 35 mm; D3: 70 mm; L: 40 mm; Weight: 0.40 kg
• DN 40 — D1: 38 mm; D2: 41 mm; D3: 78 mm; L: 41 mm; Weight: 0.50 kg
• DN 50 — D1: 50 mm; D2: 53 mm; D3: 92 mm; L: 43 mm; Weight: 0.70 kg
• DN 65 — D1: 66 mm; D2: 70 mm; D3: 112 mm; L: 48 mm; Weight: 1.10 kg
• DN 80 — D1: 81 mm; D2: 85 mm; D3: 127 mm; L: 54 mm; Weight: 1.61 kg
• DN 100 — D1: 100 mm; D2: 104 mm; D3: 148 mm; L: 64 mm; Weight: 2.27 kg
• DN 125 — D1: 125 mm; D2: 129 mm; D3: 178 mm; L: 58 mm; Weight: 3.10 kg
• DN 150 — D1: 150 mm; D2: 154 mm; D3: 210 mm; L: 60 mm; Weight: 5.30 kg

Additional product information

• Borosilicate glass provides sealing per DIN 7080; where glass temperature limits are exceeded, a mica protective disc can be fitted for additional protection against temperature and steam.
• Sealing materials available: NBR, EPDM, silicone, FKM (Viton®) or PTFE (milk-pipe compatible options).
• Internal surface finish: Ra ≤ 0.8 μm.
• Suitable for liquid and gaseous media; custom designs and accessories (wipers, lights, coatings) available on request.
• Typical maximum working pressure: up to 10 barg (PN 10) depending on configuration.

Technical specifications

• Model / Type: Type 327
• Manufacturer: ACI Industriearmaturen GmbH
• Standards: DIN 11851 / EN 10357; glass sealing per DIN 7080
• Nominal sizes: DN 25 – DN 150
• Nominal pressure: PN 6 and PN 10 (working pressure up to 10 barg)
• Temperature resistance: up to 200 °C (depending on glass and configuration)
• Materials: stainless steel construction; borosilicate sight glass; O-ring options: NBR, EPDM, silicone, FKM (Viton®), PTFE
• Internal surface finish: Ra ≤ 0.8 μm
• Options: SGW wiper (PTFE/silicone), LED illumination (non-Ex), FEP or Halar® coatings, mica protective disc
• Typical applications: hygienic processes in food, pharmaceutical and medical industries
