Vacuum sight glass Type 390V
stainless steelborosilicate glassweld-on

Vacuum sight glass - Type 390V - ACI Industriearmaturen GmbH - stainless steel / borosilicate glass / weld-on
Vacuum sight glass - Type 390V - ACI Industriearmaturen GmbH - stainless steel / borosilicate glass / weld-on
Vacuum sight glass - Type 390V - ACI Industriearmaturen GmbH - stainless steel / borosilicate glass / weld-on - image - 2
Vacuum sight glass - Type 390V - ACI Industriearmaturen GmbH - stainless steel / borosilicate glass / weld-on - image - 3
Vacuum sight glass - Type 390V - ACI Industriearmaturen GmbH - stainless steel / borosilicate glass / weld-on - image - 4
Add to favorites
Compare this product

Characteristics

Specifications
for vacuum, stainless steel, borosilicate glass, weld-on
DN

Min.: 15 mm
(0.6 in)

Max.: 350 mm
(13.8 in)

Temperature

Min.: 80 °C
(176 °F)

Max.: 200 °C
(392 °F)

Operating pressure

Min.: 0 bar
(0 psi)

Max.: 16 bar
(232 psi)

Description

Overview
  • Type 390V circular sight glass fitting designed for observation and optional illumination of the interior of containers and pipelines in vacuum applications up to positive pressure.
  • Welded to a pipe socket or container wall; borosilicate sight glass (DIN 7080) clamped between two stainless steel flanges with selected gaskets.


Main features
  • Application range: vacuum to positive pressure (typical range −0.9 barg to max. 16 barg).
  • Material: stainless steel 1.4571 (316Ti) for flanges and housing.
  • Standard glass: borosilicate glass according to DIN 7080 (or customer specification).
  • End connection: welding ends according to DIN EN 1092-1 type 11.
  • Sealing: D‑ring or O‑ring gaskets; gasket materials include PTFE (Teflon®), NBR, silicone, EPDM, FKM.
  • Temperature resistance: up to 200 °C (various temperature ratings available).


Options
  • LED illumination (available for Ex and Non-Ex areas).
  • FEP or Halar® coating to protect the borosilicate glass against aggressive chemicals or alkalis.
  • Custom designs and special materials on request.


Accessories (examples)
  • FEP protective screen / coating for additional chemical protection of the sight glass plate.
  • LED lights in different designs for interior illumination.


Construction / components (exploded view)
  • Screws
  • Cover flange
  • Glass cushion
  • Sight glass
  • D‑ or O‑ring
  • Base flange
  • Nuts


Dimensions (PN 16 and related PS rows) — table rows
  • PN 16 — DN 15: Da 95 mm; Di 17 mm; A 21,3 mm; s 2 mm; Seal design: D‑ring DIN 11851; Weight: 1,6 kg
  • PN 16 — DN 20: Da 105 mm; Di 22 mm; A 26,9 mm; s 2,3 mm; Seal design: D‑ring DIN 11851; Weight: 2,3 kg
  • PN 16 — DN 25: Da 115 mm; Di 28 mm; A 33,7 mm; s 2,6 mm; Seal design: D‑ring DIN 11851; Weight: 2,7 kg
  • PN 16 — DN 32: Da 140 mm; Di 37 mm; A 42,4 mm; s 2,6 mm; Seal design: D‑ring DIN 11851; Weight: 4,0 kg
  • PN 16 — DN 40: Da 150 mm; Di 43 mm; A 48,3 mm; s 2,6 mm; Seal design: O‑ring; Weight: 4,4 kg
  • PN 16 — DN 50: Da 165 mm; Di 54 mm; A 60,3 mm; s 2,9 mm; Seal design: O‑ring; Weight: 5,3 kg
  • PN 16 — DN 65: Da 185 mm; Di 70 mm; A 76,1 mm; s 2,9 mm; Seal design: D‑ring DIN 11851; Weight: 6,5 kg
  • PN 16 — DN 80: Da 200 mm; Di 83 mm; A 88,9 mm; s 3,2 mm; Seal design: D‑ring DIN 11851; Weight: 8,4 kg
  • PN 16 — DN 100: Da 220 mm; Di 107 mm; A 114,3 mm; s 3,6 mm; Seal design: D‑ring DIN 11851; Weight: 9,8 kg
  • PN 16 — DN 125: Da 250 mm; Di 132 mm; A 139,7 mm; s 4 mm; Seal design: D‑ring DIN 11851; Weight: 13,3 kg
  • PN 16 — DN 150: Da 285 mm; Di 160 mm; A 168,3 mm; s 4,5 mm; Seal design: O‑ring; Weight: 17,1 kg
  • PS 10¹ — DN 200: Da 340 mm; Di 207 mm; A 219,1 mm; s 6,3 mm; Seal design: O‑ring; Weight: 25,1 kg
  • PS 6¹ — DN 250: Da 405 mm; Di 260 mm; A 273 mm; s 6,3 mm; Seal design: O‑ring; Weight: 37,4 kg
  • PS 6¹ — DN 300: Da 460 mm; Di 310 mm; A 323,9 mm; s 7,1 mm; Seal design: O‑ring; Weight: 49,3 kg
  • PS 6¹ — DN 350: Da 520 mm; Di 340 mm; A 355,6 mm; s 8 mm; Seal design: O‑ring; Weight: 70 kg


Characteristics / specifications
  • Model: Type 390V
  • Application: vacuum to max. 16 barg (typical range −0.9 barg to 16 barg)
  • Nominal pressure (standard): PN 16 (additional PS rows available as per table)
  • Nominal sizes: DN 15 – DN 350
  • Face-to-face / connection: welding ends (DIN EN 1092-1 type 11)
  • Body material: stainless steel 1.4571 (316Ti)
  • Glass material: borosilicate glass (DIN 7080) or per customer specification
  • Seal types: D‑ring (DIN 11851) or O‑ring; gasket materials: PTFE (Teflon®), NBR, silicone, EPDM, FKM
  • Optional coatings: FEP or Halar®
  • Optional illumination: LED lights (Ex and Non-Ex variants)
  • Temperature rating: up to 200 °C (various temperature options listed)
  • Suitable media: liquid and gaseous media
  • Custom designs and accessories available on request
