TFT LCD display module ASK0125SA01T2424C11C01

IPSCircular Knobdot-matrix

Product overview
1.25-inch round LCM (LCD module) integrated with a smart knob module, designed for smart home accessories and control panels. One-stop OEM/ODM solution for panel integrators and device manufacturers. Module provides a round TFT IPS display without touch input and supports serial and USB interfaces.

Key specifications

• Model NO.: ASK0125SA01T2424C11C01
• Product type: LCM (LCD module) with smart knob
• Screen size/format: 1.25-inch round display (glass electronic product)
• Touch screen type: No Touch
• Display technology: TFT
• Viewing angle: IPS
• DOT-Matrix Graphic LCD Module type: Row/Column-Driven Control Type
• LCD drive mode: Multiplex Drive LCD Module
• Response time: 30 ms
• Brightness: 350 cd/m²
• Color depth: 65K
• Connection: 6-pin serial port
• Interface: USB
• Customized: Available (OEM/ODM)
• Trademark: ASK
• Origin: China
• HS Code: 8531200000
• Production capacity: 1000 PCS/Month
• Package size: 10.00 cm x 10.00 cm x 2.00 cm
• Package gross weight: 0.100 kg

Interface and integration
The module supports a 6-pin serial connection and USB interface for data and power integration. Designed for panel mounting and direct PCB integration; consult ASK technical documentation for pinout, timing diagrams and recommended PCB footprint. Custom mechanical options and firmware adaptations are available through OEM/ODM services.

Packaging and logistics
Delivered in carton transport packaging. Standard package dimensions and gross weight are listed above; shipping and export handled per HS Code 8531200000. Production capacity and packing options can be adjusted for volume orders.

Ordering and support
Contact ASK for samples, customization requirements, lead times and volume pricing. Technical drawings, electrical specifications and integration support are provided to buyers and integrators to speed up development and production.
