Ball valve MBVT-1010.-.
manualshut-offdiverter

ball valve
ball valve
ball valve
Add to favorites
Compare this product

Go to the Beswick Engineering Co, Inc. website for more information

Characteristics

Type
ball
Operation
manual
Function
shut-off, diverter, selector
Media
for water, for oil, for chemical products, for fuel, for gas, for air
Body
threaded, miniature, stainless steel
Applications
for the chemical industry, for the food industry, for pharmaceutical applications, for vacuum, instrumentation, for medical applications, high-purity, laboratory, for the semiconductor industry
Number of channels
3-way
Other characteristics
compact, corrosion-resistant, high-performance, with seal, chemical-resistant, multi-directional
DN

1.78 mm
(0.07 in)

Pressure

500 psi

Description

Beswick MBVT-1414 is a miniature ¼-28 threaded selector ball valve this is manufactured using stainless steel materials. It is an excellent choice for application requiring a port selection valve. The MBVT-1414 allows bi-directional flow between a common inlet port on the bottom of the valve, and one of two selectable ports on either side. There is also an “off” position. This design offers compact size, light weight, and flow equivalent to a 1/8” (3.75 mm) effective orifice. The design is rated up to (34.5bar) 500 psig and contains O-ring seals for a leak tight fit.
