Parallel-shaft gearmotor 261 SeriesACgear trainsolid-shaft
Add to favorites
Compare this product
fo_shop_gate_exact_title
Characteristics
- Motor type
- AC
- Type
- gear train
- Shaft orientation
- parallel-shaft
- Shaft configuration
- solid-shaft
- Power
- 100 W...500 W, 50 W...100 W
- Voltage
- 380 V, 460 V
- Torque
- 20 - 50 Nm, 10 - 20 Nm, 1 - 5 Nm, 5 - 10 Nm
- Product applications
- for the food industry, for agricultural applications, for the packaging industry, washdown
- Other characteristics
- modular, stainless steel, maintenance-free, in-line, IP69K
- Gear ratio
Max.: 221 unit
Min.: 5 unit
Description
8-350 RPM · 16-500 in-lbs · 1/7 and 1/8 HP · AC Inverter Duty Motor
IP69K washdown rated
Motor and gear train enclosed in one sealed stainless steel shell.
Two part, spring loaded stainless steel and EPDM triple lip shaft seal.
304 stainless steel cover
EPDM O-rings for a tight seal
316 stainless steel, o-ring sealed hex bolts hold cover in place.
Stainless steel output shaft with captured keyway.
Modular gear train incorporates sealed ball bearings and is capable of high load conditions.
Food grade H1 grease is used for maintenance-free lifetime lubrication.
Laser marked motor nameplate
Removable IP69K ABS cordset connects to stainless steel multi-pin connector.
230 V, 60/50 Hz, inverter duty motor.
IP69K Rated
Stainless steel IP69K rated design will stand-up to the pressurized hot water and chemicals used in the washdown process.
Continuous Duty
Motors rated for continuous duty operation.
Durable & Reliable
Rugged design withstands the harshest, most demanding operating environments.
Markets & Applications
Food & Beverage Packaging
Food & Beverage Preparation
Food & Beverage Processing
Food & Beverage Service
Agricultural Equipment
