Medium excavator CX140E

crawlerdiesel

Overview
The CX140E is a transportable large-class crawler excavator engineered for balanced performance and mobility. At approximately 13,100 kg (28,900 lb) it combines compact transportability with a 102 hp powertrain and 21,400 lb breakout force. New engine and hydraulic calibrations improve transient response, torque delivery and fuel efficiency. Four selectable working modes adapt machine response to task requirements.

Quick specifications

• Rated power: 102 hp | 76.4 kW
• Operating weight: 28,900 lb | 13,100 kg (approx.)
• Breakout force: 21,400 lb (approx.)

Standard equipment

• Engine: FPT NEF4, Tier 4 Final / Stage V certified
• Selective Catalytic Reduction on Filter (SCRoF)
• Four-cylinder turbocharged diesel
• 1000-hour engine oil/filter interval
• 24-volt electrical system
• Telematics: myCASEConstruction hardware with 7-year advanced data subscription

Optional equipment

• High ambient temperature cooling package
• Auxiliary hydraulics: proportionally controlled secondary low-flow circuit
• Hose Burst Check Valve (HBCV)
• Machine control: Leica iCON iXE2 (2D), Leica iCON iXE3 (3D)
• Attachments: quick coupler / Case multi-pin grabber; heavy-duty, extreme-duty and ditching buckets; hammers; thumbs; compaction plates

Undercarriage

• 500 mm (19.7 in) rubber link chain with bolt-on rubber pads on steel chain
• 700 mm (27.6 in) steel shoes, triple semi-grouser
• Double track chain guides

Operator environment

• Spacious cab with 10-inch LCD monitor, climate controls and camera display
• FOPS cab top guard — Level 2
• Front grill and rock guard options (one-piece and two-piece OPG)
• Max View Monitor: 3 cameras providing up to 270° visibility
• LED package: 8 LEDs (front, rear, boom, house, sides)

Warranty

• 3-year / 3,000-hour full-machine factory warranty
• 7-year advanced myCASEConstruction subscription

Technical specifications

• Model: CX140E
• Engine: FPT NEF4, 4-cylinder turbocharged diesel; Tier 4 Final / Stage V; SCRoF
• Rated power: 102 hp | 76.4 kW
• Operating weight: 28,900 lb | 13,100 kg (approx.)
• Breakout force: 21,400 lb (approx.)
• Working modes: Super Power, Power, Eco, Lifting
• Hydraulics: improved transient response with customizable flow priority; optional proportional low-flow auxiliary circuit; optional HBCV
• Electrical: 24-volt system
• Maintenance: 1000-hour engine oil/filter interval
• Cab: 10-in LCD, climate control, camera display, FOPS Level 2
• Vision & safety: Max View Monitor (3 cameras), multiple guard options
• Lighting: 8 LED units
• Undercarriage options: 500 mm rubber link chain with bolt-on pads; 700 mm steel shoes triple semi-grouser
• Attachments compatibility: quick coupler / Case multi-pin grabber; buckets; hammers; thumbs; compaction plates
• Telematics: myCASEConstruction hardware with 7-year advanced data subscription
