Centrifugal pump AQUAPROF
waterelectricnormal priming

Centrifugal pump - AQUAPROF - DAB - water / electric / normal priming
Centrifugal pump - AQUAPROF - DAB - water / electric / normal priming
Centrifugal pump - AQUAPROF - DAB - water / electric / normal priming - image - 2
Centrifugal pump - AQUAPROF - DAB - water / electric / normal priming - image - 3
Centrifugal pump - AQUAPROF - DAB - water / electric / normal priming - image - 4
Add to favorites
Compare this product

Characteristics

Technology
centrifugal
Fluid
water
Operation
electric
Priming
normal priming
Mobility
stationary
Domain
industrial
Applications
distribution
Protection level
IP42
Flow

Min.: 5.1 m³/h
(180.1048 ft³/h)

Max.: 85 m³/h
(3,001.74667 ft³/h)

Pressure

Min.: 0 bar
(0 psi)

Max.: 6 bar
(87.023 psi)

Head

Min.: 0 m
(0'00" )

Max.: 48 m
(157'05" )

Power

10 kW
(13.6 hp)

Fluid temperature

Min.: 5 °C
(41 °F)

Max.: 35 °C
(95 °F)

Length

470 mm
(19 in)

Width

300 mm
(11.81 in)

Height

550 mm
(21.65 in)

Weight

18 kg, 19 kg
(39.68 lb, 41.89 lb)

Description

The AQUAPROF unit is used for rainwater management and distribution. The unit detects any faults in the water collection system, whether from rainwater or the mains and makes corrections to ensure proper operation of the plant (that is, it does not ever leave the connected utilities dry). It signals any faults and displays the problem detected. APPLICATIONS The AQUAPROF unit is used for rainwater management and distribution. The unit detects any faults in the water collection system, whether from rainwater or the mains and makes corrections to ensure proper operation of the plant (that is, it does not ever leave the connected utilities dry). It signals any faults and displays the problem detected. Generally, this system is reserved for irrigation, clothes washing, WC flushing and floor cleaning applications. The primary purpose of the AQUAPROF system is to give use of the rainwater priority over the use of the mains water. When there is not enough rainwater in the collection tank, the control unit switches over to the mains, ensuring that the connected use points are supplied (PLEASE, NOTE the water supplied by this system is not potable). The connection between the rainwater collection tank and the mains water collection tank in
