Product overview
The Delta Array BeamBar-Red is an array laser bar combining 10 high-power red diode laser outputs (637 nm) with 10 RGB LED rings (80 RGB diodes total) to create curtain and beam effects. Designed for medium to large events, it supports Art‑Net, DMX‑512 and USB control and can run in Auto mode for standalone shows. The Art‑Net interface enables seamless integration into larger entertainment installations.

Key features

• Guaranteed total output laser power: 1700 mW
• Red lasers: 10 outputs, 637 nm, 170 mW each
• LED rings: 10 rings × 8 RGB diodes (80 RGB diodes total)
• Control: Art‑Net, DMX‑512, USB, Auto‑mode
• OLED display for setup and status
• Protection class IP44 for indoor and covered outdoor use

Technical specifications

• Optical laser power (mW): 170 (per individual output)
• Guaranteed total output laser power: 1700 mW
• Red laser modules: 10 pcs
• Wavelength: 637 nm
• Beam specifications: approx. 3.0 mm / 1 mrad
• Laser technology: Diode
• Laser class: 3B
• LED rings: 10 rings × 8 RGB diodes (total 80 RGB diodes)
• Control signal: Art‑Net, DMX‑512, USB, Auto‑play
• DMX modes: 14ch, 16ch, 22ch, 43ch, 250ch, 253ch
• Protection class: IP44
• Operating temperature: 10°C to +40°C
• Power consumption: 65 W (220 VAC)
• Power supply: 90–230 VAC / 50–60 Hz
• Weight: 8 kg
• Dimensions (W × D × H): 1000 × 116 × 73 mm

Applications

• Stage and concert beam/curtain effects
• Nightclubs and DJ shows
• Themed events and touring productions
• Integration into fixed installations and lighting rigs via Art‑Net

Accessories & compliance

• Included: 1.5 m power lead
• Optional: flight case (on request)
• Safety: Laser class 3B — follow applicable regulations for installation and operation
