Progressive cavity pump JP-700 SR

for chemicalselectricsubmersible

Drive with electric or air operated motor and planetary gear Particularly for intermittent operation. For gentle and almost pulsation free transferring of low viscous to highly viscous, thixotropic, gassy, solids and fibres containing, aggressive and neutral media. Pump tube will be driven by electric universal or air operated motors. All pump parts are made of stainless steel 316Ti. The stators are adapted to the medium and available in NBR, NBR light, FKM, EPDM, EPDM light, PTFE. Discharge pressure 6 bar at the single-stage and 12 bar with the two-stage pump tubes. The maximum viscosity of the medium is 10,000 mPas at the SR version. Special lengths up to 2,000 mm on request. Easy disassembling and therefore optimal cleaning. Weight 12 kg. Special version for food, cosmetic and pharmaceutical products can be delivered: polished surfaces, either open or encapsulated pin joints, no dead spaces in the pump, easy disassembling and therefore easy cleaning, milk thread connection DN 11851, CIP connections as an option, stator and sealing materials in food grade FDA, also PTFE stators available.
