Pneumatic test fixture

Description
The LiTeM modular pneumatic test systems include three main components:

• Real Time controller RTC
• Pneumatic actuator K-PN
• Modular frame (available as MF-P, BYC or custom per customer drawing)

Systems can be configured as single-axis or multi-axis. Actuators have variable characteristics and are easily interchangeable; test frames can be arranged in non-standard shapes and sizes. The modular design enables numerous configurations for different test types and specimen dimensions. Actuator(s) can be positioned at any point on the frame using dedicated LiTeM supports.

Utilities / Functional features

• Oil-free operation
• Low consumption
• High flexibility
• Tabletop configuration options
• Easy operation
• Video tutorials available

Application fields

• Biomedical
• R&D
• Plastics
• Rubbers
• 3D printing (plastic and metal)
• Composite materials
• Springs
• Mechanical components
• Assembled components including large-size items

Gallery
Multiple images available showing configurations and details of the LiTeM modular pneumatic frame.

Characteristics / technical specifications

• Main components: Real Time controller RTC, Pneumatic actuator K-PN, Modular frame (MF-P, BYC or custom)
• Configuration: single-axis or multi-axis
• Actuators: interchangeable with variable characteristics
• Frames: configurable in non-standard shapes and sizes
• Actuator positioning: possible at any point using dedicated supports
• Key benefits: modularity, low consumption, oil-free operation, ease of use, suitable for tabletop solutions and custom test benches
