Piston pressure switch PPC seriesSPDTDIN railG 1/4
Add to favorites
Compare this product
Characteristics
- Technology
- piston
- Contact type
- SPDT
- Mounting
- DIN rail
- Process connection
- G 1/4
- Material
- stainless steel
- Protection level
- ATEX, IP65
- Other characteristics
- adjustable, ATEX, flange, IP65
- Pressure range
Max.: 300 bar
(4,351.13 psi)Min.: 0.15 bar
(2.18 psi)- Switching power: current
2 A, 3 A
- Process temperature
Max.: 140 °C
(284 °F)Min.: -25 °C
(-13 °F)
Description
Piston pressure switch with 2 spdt contacts
Max. static pressure - 600 bar
Hysteresis - 30% of set-point
Diaphragm/ Seal material - NBR – FKM – Silicone – HNBR
Dimensions - Body 30 x 30 – Max. high92 mm
Certification - CE – ATEX – RINA – Lloyd’s Register – UR
Options - Set-point rising and falling – Gold-plated contacts for low current – Tested for applications with gas – Microswitch for – Led for – Connector
Catalogs
Pressure and Vacuum switches
67 Pages
