Needle valve RKVwith handwheelregulatingfor water
Add to favorites
Compare this product
Characteristics
- Type
- needle
- Operation
- with handwheel
- Function
- regulating
- Media
- for water
- DN
Max.: 300 mm
(11.811 in)Min.: 100 mm
(3.937 in)- Pressure
Max.: 160 bar
(2,320.6 psi)Min.: 40 bar
(580.2 psi)
Description
DN 100 - 300
PN 40 - 160
Body: EN-JS 1050
Coating: Epoxy, special coatings
Proven technology in flexible, single-component design for higher pressure ratings
Designed at one Piece
Safe energy conversion through constant annular cross-section
Change in cross-section through axially movable internal piston
Flexible regulatting inserts depending on application
Available as sonstricted version (RKVE) for special installation situations
Also suitable as valves for air regulation in aeration tanks in sewage treatment plants
