analog time relay / multi-function / time delay / DIN rail mounted



  • Technology:


  • Function:

    multi-function, time delay

  • Mounting:

    DIN rail mounted

  • Voltage:

    Max.: 240 V

    Min.: 12 V


The multi-functioning time relay is available in CRM-91H and CRM-93H. It has a single module and can be mounted on DIN rail and a 12V-240V in AC or DC universal supply voltage. It has 10 functions divided into three, supply voltage controls 5 time functions, contol input controls 4 time functions and the last 1 function is for memory or latching relay. It has 0.1s-10days time scale split into 10 ranges. Rotary switch sets time, the product can be easily set. It has CRM-91H 1x16A or CRM-93H 3x8A changeover output contacts. Flashing of multi-function red LED indicates output.
