Hand pallet truck FPBF W 685

hydraulicsteel

Manual pallet truck for fruits and vegetables with a robust drawn steel structure and rounded fork tips. The hydraulic unit is entirely made of steel and mounted on a high-precision thrust bearing. It features a 3-position control lever with adjustable lowering speed. Lifting is operated by a tiller with automatic return to the upright position. Safety valves are included for hoist limit and overload protection. The truck is equipped with directional aluminum wheels with elastic rubber, diameter 180 mm, mounted on ball bearings, and nylon load rollers, diameter 74 mm, with double ball bearings. - Capacity: 2500 kg - Maximum fork height: 190 mm - Minimum fork height: 75 mm - Overall width: 685 mm - Fork length: 1220 mm - Fork width: 160 mm - Weight: 80 kg - Steering wheels: Rubber - Front rollers: Nylon Available on request in galvanized version and with a capacity of 3000 kg.
