Hydraulic pallet truck TPWN09

multifunctionliftweight indicator

The TPWN09 NETWORK pallet truck is equipped with integrated electronic weighing, making it handy and easy to use. It features 4 shear-beam load cells for enhanced precision and a multifunction weight indicator with a large backlit display for optimal readability even in low light conditions. This series is not approved for legal trade. Available in two models: - TPWN09: Fork width 550 mm, division 0.2 kg, capacity 2000 kg. - TPWN09L: Fork width 680 mm, division 1 kg, capacity 2000 kg, ideal for the fruit and vegetable sector. Main Features: - Lightweight and robust for precise weighing. - Wide fork version available for specific sectors. - Load cell adjustment via display. - Constructed with 4 steel load cells, IP67 protection. - 25 mm backlit shockproof LCD display. - Waterproof keyboard for industrial use. - Internal rechargeable battery with 80h autonomy. - Programmable automatic shutdown. - Low profile forks with 85 mm height. - Lifting height 200 mm. - Weight approximately 105 kg. - Oven-painted steel structure. - Polyurethane wheels and rollers. - Quick lift hydraulic pump. - Battery charger included (approx. 8h charging time). - Operating temperature: -10°C to +40°C. Main Functions: - High resolution x10 display. - Net/gross or lb/kg conversion. - Weight totalization. - Formulation and percentage weighing. - Piece counter and +/- control. Keyboard Functions: - Zeroing, semi-automatic tare, manual tare. - lb/kg conversion and free conversion factor. - Weight totalization and piece counter.
