Steel pin CP700 series
standard-duty

Steel pin - CP700 series - Fixtureworks - standard-duty
Steel pin - CP700 series - Fixtureworks - standard-duty
Steel pin - CP700 series - Fixtureworks - standard-duty - image - 2
Add to favorites
Compare this product
Go to the Fixtureworks website for more information

Characteristics

Material
steel
Applications
standard-duty

Description

Rotating the handle projects the locating pin after the workpiece is set on supports. This allows loading and unloading of the workpiece smoothly without projecting locating pins. The body is made from 1045 alloy steel and the piston is made from 4140 alloy steel. Parts are heat treated with a black oxide finish. Knob is black plastic.
