Pin and bush coupling N-EUPEX DS
for pumpsfor compressorsfor blowers

pin and bush coupling
pin and bush coupling
Add to favorites
Compare this product


Characteristics

Type
pin and bush
Product applications
for pumps, for compressors, for blowers
Installation system
flange
Torque

Min.: 60 Nm (44.2537 ft.lb)

Max.: 21,200 Nm (15,636.3176 ft.lb)

Description

Damping shaft coupling that can be used universally to compensate for shaft misalignments Nominal torque range from TKN = 60 Nm up to 21,200 Nm with 19 sizes Temperature range: from –50 °C to +100 °C Robust and proven a million times N-EUPEX DS® couplings do not have a fail-safe device, allowing positive disconnection of the input and output side upon failure of the flexible elements due to overload or wear. Then, the metal parts of the DS coupling can rotate freely in opposite directions. Your benefits at a glance Can be used universally and combined with many components of the N-EUPEX line Disconnects driver and driven machine if elastomer fails No fail-safe principle operation (the load is disconnected) Suitable for use in potentially explosive environments; certified according to 2014/34/EU (ATEX) Maintenance-free even if used in explosive atmospheres Many types are available ex stock Established as an industrial standard, worldwide in use Mining and Cement: heating technology Oil and Gas: pumps, fans, compressors, air condensers Power Generation: pumps, fans, compressors, air condensers, water turbines Chemicals and Pharmaceuticals: driers, lauter tuns, pumps, fans, compressors, mixers drives, agitators, reactors Pulp and Paper: wastewater purification plants Water and Wastewater: aerators Food and Beverage: lauter tuns, reactors, agitators, mixers
