Relative pressure transmitter DeltaSpan™ LD30 series

membrane4-20 mAjunction box

The general purpose external mount pressure level transmitter is offered in two styles of termination and provides continuous level measurement up to 69’ (21m) of water column with a 4-20 mA signal output. Select the -S_01 level sensor for cable termination or the -S_11 level sensor for conduit termination with an integral junction box. This liquid or air level sensor is well suited for clean liquid or gas media. Applications include cutting oil and air. FEATURES Corrosion resistant 316 SS transducer with threaded mount Available with polyurethane cable or junction box termination Automatic temperature compensation for accurate measurement Configuration: None, fixed span Supply voltage: 13-30 VDC Loop resist.: 1300 Ohms max @ 30 VDC Response time: 50ms Weight: 10 oz (283 g) Enclosure rating: NEMA 4X (IP65) Enclosure mat.: 316 SS Termination: -SX01: Cable, -SX11: Junction box with 1/2” NPT conduit Cable type: -SX01: 2-cond., shielded Cable length: -SX01: 9’ (2.7m) Cable material: -SX01: Polyurethane Process mount: 1/4” NPT Sensor material: 316 SS Classification: General purpose Compliance: CE
