Insulation tester GT-KB47

for shoesR&Dlaboratory

Product Introduction
Shoe Material Heat Insulation Tester GT-KB47 is designed to measure the heat insulation performance of a whole shoe. The specimen (a whole shoe) is placed on a heated plate with a controlled temperature and the temperature rise inside the shoe is recorded to evaluate insulation properties.

Application
Used for determining thermal insulation of footwear in R&D, quality control and compliance testing. Applicable to testing whole shoes according to relevant standards to assess temperature rise under specified conditions.

Product Details

• Brand: GESTER
• Item NO.: GT-KB47
• Order (MOQ): 1
• Payment: T/T, L/C
• Shipping Port: Xiamen Port
• Lead Time: 10-30 days

Key Specifications

• Model: GT-KB47
• Sand bath size: (40 ± 2) × (40 ± 2) cm; height ≥ 5 cm
• Sand granular size: 0.3–1.0 mm
• Hotplate temperature range: RT to 250 °C ± 5 °C
• Temperature probe: soldered to a copper disc 2 mm thick, 15 mm dia.; accuracy ±0.5 °C
• Heat transfer medium: 5 mm steel balls, total mass (4000 ± 40) g
• Heating power: ≥ 2500 ± 250 W
• Power supply: Single-phase AC 220 V 50/60 Hz
• Dimensions (W×D×H): 36 × 24 × 47 cm
• Weight: 40 kg
• Standards: ISO 20344-2021 (section 5.15); GB/T 20991 (section 5.12); AS/NZS 2210.2 (section 5.12)
• Standard accessories: temperature probe (1 set); 5 mm steel balls (4 kg); power line (1 pc)

Technical Specifications

• Model: GT-KB47
• Sand bath: (40 ± 2) × (40 ± 2) cm, height ≥ 5 cm
• Granular size: 0.3–1.0 mm
• Temperature range: RT–250 °C ± 5 °C
• Probe: copper disc 2 mm thick, 15 mm dia., accuracy ±0.5 °C
• Heat medium: 5 mm steel balls, (4000 ± 40) g
• Power: ≥ 2500 ± 250 W; Supply: 1φ AC 220 V 50/60 Hz
• Size (W×D×H): 36 × 24 × 47 cm; Weight: 40 kg
• Compliant standards: ISO 20344-2021 §5.15; GB/T 20991 §5.12; AS/NZS 2210.2 §5.12
• Accessories included: temp. probe (1 set), 5 mm steel balls (4 kg), power line (1 pc)
