Pneumatic grease pump CompAlube

electricgear

Overview
The Groeneveld CompAlube is a compact all-in-one single-line automatic lubrication system for machines and vehicles with low-to-moderate grease demand. The unit integrates pump, control, distribution block and metering units and uses a replaceable 1.8 kg grease cartridge for clean, tool-free cartridge changes. The compact design and internal distribution allow flexible mounting and installation in confined spaces.

Key features

• All-in-one unit: pump, control, distribution block, metering units and 1.8 kg grease cartridge integrated in a single compact assembly.
• Drive options: electric gear pump or pneumatic plunger pump.
• Lubrication capacity: up to 19 outlets (lubrication points).
• Cartridge system: quick, clean, tool-free replacement; eliminates refilling and reduces contamination risk.
• Integrated distribution block and range of metering units to adjust grease delivery per lubrication point.
• Recommended lubricant consistency: NLGI-0.

Technical data

• Operating principle: Electric gear pump or pneumatic plunger pump
• Outlets: Max. 19
• Delivery volume: 20 cm3 per stroke
• Lubricant: NLGI-0
• Operating temperature: -25°C to +80°C (-13°F to +160°F)
• Operating pressure: Max. 250 bar (3625 psi)
• Reservoir: 1.8 kg cartridge
• Power supply: 12 or 24 V
